Main Sub
Item Content
Adjustment
code code range
08 Checks
developing bias
voltage output.
SIMULATION NO. 8- _
1.DEVELOPING BIAS VOLTAGE SETTING
AND OUTPUT
2.MAIN CORONA SETTING AND OUTPUT
6.TRANSFER CORONA OUTPUT
7.SEPARATION CORONA OUTPUT
INPUT SUB NO. AND PRESS PRINT SWITCH
01 Sets and
checks
developing bias
voltage.
• Execution wait mode
SIMULATION NO. 8- 1
DEV. BIAS VOLTAGE SETTING AND OUTPUT
AUTO EXPOSURE MODE [XXX] :XXX [V]
MANUAL EXPOSURE MODE [XXX] :XXX [V]
PHOTOGRAPHIC MODE [XXX] :XXX [V]
SOFT PHOTOGRAPHIC MODE [XXX] :XXX [V]
TONER SAVE MODE [XXX] :XXX [V]
PRINTER MODE [XXX] :XXX [V]
(0~700)
[→]KEY: MOVE PRINT SW: EXECUTE
0-700
0-700
0-700
• Developing bias voltage output in progress
SIMULATION NO. 8- 1
DEV. BIAS VOLTAGE OUTPUT
AUTO EXPOSURE MODE
DEV. BIAS VOLTAGE [XXX]
[PAUSE]KEY: END OUTPUT CHECK
SIMULATION NO. 8- 1
DEV. BIAS VOLTAGE OUTPUT
MANUAL EXPOSURE MODE
SIMULATION NO. 8- 1
DEV. BIAS VOLTAGE OUTPUT
PHOTOGRAPHIC MODE
