Main Sub
Item Content
Adjustment
code code range
08 01 Sets and
checks
developing bias
voltage.
0-700
0-700
0-700
SIMULATION NO. 8- 1
DEV. BIAS VOLTAGE OUTPUT
SOFT PHOTOGRAPHIC MODE
SIMULATION NO. 8- 1
DEV. BIAS VOLTAGE OUTPUT
TONER SAVE MODE
SIMULATION NO. 8- 1
DEV. BIAS VOLTAGE OUTPUT
PRINTER MODE MODE
[Content] If the [PRINT] key is pressed after entering a sub code, the copier enter the
execution wait mode and the ready lamp comes on, with the current developing
bias voltage setting displayed. At this time, the setting can be changed with the
numeric keypad and updated by pressing the [PRINT] key. (The cursor indicates
the same developing bias item.) If the [PRINT] key is pressed without entering any
new setting, the ready lamp goes out and the developing bias voltage is output at
the current setting for 30 seconds. After outputting, the screen returns to the
execution wait mode screen.
Setting Developing bias (Approx.)
0: 0 V
700: –700 V
<Note> The set value does not coincide with the output voltage.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated.
(The input field remains at the same place.)
If the entered value is not valid, the entered value is cleared and the
error buzzer sounds. If the [PRINT] key is pressed without entering any
new setting, the developing bias voltage is output without updating the
setting. (The developing bias voltage in the input field selected at that
time is output.)
[0-9]: Enters developing bias voltage settings
[→]: Moves the input field.
[C]: Clears the entered value.
[PAUSE]: Stops the execution of the simulation and returns the screen to the execu-
tion wait mode.
[CA]: Stops the execution of the simulation and terminates the simulation.
02 Sets and
checks
charging/grid
output.
• Execution wait mode
SIMULATION NO. 8- 2
MAIN CORONA SETTING AND OUTPUT
AUTO EXPOSURE MODE [XXX] :XXX [V]
MANUAL EXPOSURE MODE [XXX] :XXX [V]
PHOTOGRAPHIC MODE [XXX] :XXX [V]
SOFT PHOTOGRAPHIC MODE [XXX] :XXX [V]
TONER SAVE MODE [XXX] :XXX [V]
PRINTER MODE [XXX] :XXX [V]
(200~900)
[→]KEY: MOVE PRINT SW: EXECUTE
9 – 25
