Main Sub
Item Content
Adjustment
code code range
08 02 Sets and
checks
charging/grid
output.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated.
(The input field remains at the same place.)
If the entered value is not valid, the entered value is cleared and the
error buzzer sounds. If the [PRINT] key is pressed without entering any
new setting, both the charging charger voltage and the grid bias voltage
are output without updating the settings. (The charging charger voltage
and the grid bias voltage in the input field selected at that time are
output.)
[0-9]: Enters grid bias voltage settings
[ā]: Moves the input field.
[C]: Clears the entered value.
[PAUSE]: Stops the execution of the simulation and returns the screen to the sub
code input screen.
[CA]: Stops the execution of the simulation and terminates the simulation.
06 Checks transfer
charger output.
SIMULATION NO. 8- 6
TRANSFER CORONA OUTPUT
[PAUSE]KEY: END OUTPUT CHECK
[Content] The transfer charger (THV) is output for 30 seconds. After outputting, the screen
returns to the sub code input screen.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
07 Checks
separation
charger output.
SIMULATION NO. 8- 7
SEPARATION CORONA OUTPUT
[PAUSE]KEY: END OUTPUT CHECK
[Content] The separation charger is output for 30 seconds. After outputting, the screen
returns to the sub code input screen.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
09 Checks ADU
activations.
SIMULATION NO. 9- _
2.ADU SENSOR CHECK
3.ADU REAR PLATE DRIVE MOTOR ROTATION
4.ADU ALIGNMENT PLATE DRIVE MOTOR
5.GATE SOLENOID ACTIVATION
INPUT SUB NO. AND PRESS PRINT SWITCH
9 ā 27
