Main Sub
Item Content
Adjustment
code code range
09 02 Displays the
operating status
of the ADU
sensor.
SIMULATION NO. 9- 2
ADU SENSOR CHECK
DPPD1 , DPPD2 , DTPID , DPFD
DTWHPS , DTBHPS
[PAUSE]KEY: END DISPLAY
[Content] The operating status of the ADU sensor is displayed.
DPPD1: ADU paper transport detector – 1
DPPD2: ADU paper transport detector – 2
DTPID: ADU intermediate tray paper detector
DPFD: ADU paper exit detector
DTWHPS: ADU alignment plate home position sensor
DTBHPS: ADU trailing edge plate home position sensor
(a) Operation/display Reverse video when sensor data is paper presence/ ON
Normal state when sensor data is paper absence/OFF
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
03 ADU rear edge
plate aging.
SIMULATION NO. 9- 3
ADU REAR PLATE DRIVE MOTOR ROTATION
[PAUSE]KEY: END ACTIVATION
[Content]: The ADU rear edge plate operation is checked. The plate is moved to each size
positions sequentially as shown below.
[AB series]:
HP A3 B4 A4R B5R A4 B5 A5
[Inch series]:
HP 11" × 17" 11" × 14" 8
1
⁄
2
" × 11" (R) 8
1
⁄
2
" × 11"
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution is stopped and the simulation is terminated.
04 ADU alignment
plate aging.
SIMULATION NO. 9- 4
ADU ALIGNMENT PLATE DRIVE MOTOR
ROTATION
[PAUSE]KEY: END ACTIVATION
[Content] The ADU alignment plate operation is checked. The plate is moved to each size
positions sequentially as shown below.
[AB series]:
HP A3 B4 A4R B5R A4 B5 A5
[Inch series]:
HP 11" × 17" 11" × 14" 8
1
⁄
2
" × 11" (R) 8
1
⁄
2
" × 11"
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution is stopped and the simulation is terminated.
9 – 28
