Main Sub
Item Content
Adjustment
code code range
09 05 Checks the
activation of the
gate solenoid.
SIMULATION NO. 9- 5
GATE SOLENOID ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The gate solenoid of the fusing paper exit section is turned ON/OFF.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
10 Toner motor
aging.
SIMULATION NO.10
TONER MOTOR ACTIVATION
[PAUSE]KEY: END ACTIVATION
[Content] The toner motor of the developing unit is rotated.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
main code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
14 Clears troubles
(excluding
U2/PF trouble).
SIMULATION NO.14
TROUBLE CANCELLATION (EXCEPT U2/PF)
PRINT SWITCH: EXECUTE SIMULATION
[Content] All troubles other than the U2/PF are cleared. After the execution, the simulation is
automatically cleared.
(a) Operation/display
[PRINT]: The simulation is executed and terminated.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
main code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
16 Clears U2
trouble.
SIMULATION NO.16
U2 TROUBLE CANCELLATION
PRINT SWITCH: EXECUTE SIMULATION
[Content] The US trouble is cleared. After the execution, the simulation is automatically
cleared.
(a) Operation/display
[PRINT]: The simulation is executed and terminated.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
main code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 29
