Main Sub
Item Content
Adjustment
code code range
22 08 Displays RADF
counter.
SIMULATION NO.22- 8
RADF COUNTER DISPLAY
RADF: XXX,XXX
[PAUSE]KEY: END DISPLAY
[Content] The current RADF counter value is displayed.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
09 Displays ADU
counter.
SIMULATION NO.22- 9
TRAY AND ADU COUNTER DISPLAY
TRAY 1 (COPIER LOWER) : XXX,XXX
TRAY 2 (DESK UPPER) : XXX,XXX
TRAY 3 (DESK LCC) : XXX,XXX
MANUAL FEED TRAY : XXX,XXX
DUPLEX UNIT : XXX,XXX
[PAUSE]KEY: END DISPLAY
[Content] The current values of the tray and ADU counters are displayed.
FIRST TRAY Tray 1: Copier lower tray
SECOND TRAY Tray 2: Desk upper tray
THIRD TRAY (LCC) Tray 3 : Desk lower tray (LCC)
MANUAL FEED TRAY : Manual feed tray
DUPLEX UNIT : ADU
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
10 Displays staple
counter.
SIMULATION NO.22-10
STAPLE COUNTER DISPLAY
STAPLE: XXX,XXX
[PAUSE]KEY: END DISPLAY
[Content] The current value of the staple counter is displayed.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 35
