Main Sub
Item Content
Adjustment
code code range
24 09 Clears PDA/ZR
print counter.
[Content] The PDA/ZR print counter is cleared and then PDA/ZR print counter is displayed.
(a) Operation/display
[1]: The simulation is executed and the screen changes to the PDA/ZR print
counter screen.
[2]: The simulation is stopped and the screen returns to the sub code input
screen.
If any key other than [1] or [2] is pressed, the error buzzer sounds.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
12 Clears printer
counter.
SIMULATION NO.24-12
PRINTER COUNTER
WOULD YOU MIND IF CLEARING EXECUTE?
1. EXECUTE 2. CANCEL
SELECT WITH TEN KEY:
• [1] key
SIMULATION NO.24-12
PRINTER COUNTER
COMPLETED CLEARING
PRINTER COUNTER DISPLAY
PRINTER COUNTER: 000,000
[PAUSE]KEY: END DISPLAY
[Content] The printer counter is cleared and then printer counter is displayed.
(a) Operation/display
[1]: The simulation is executed and the screen changes to the printer counter
screen.
[2]: The simulation is stopped and the screen returns to the sub code input
screen.
If any key other than [1] or [2] is pressed, the error buzzer sounds.
[PAUSE]: The execution of the simulation is stopped and the screen returns to the
sub code input screen.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
25 Checks the
activation of the
main motor unit.
SIMULATION NO.25- _
1.MAIN MOTOR ACTIVATION
2.AUTOMATIC DEVELOPER REFERENCE
SETTING
3.TONER CONTROL MODE SETUP
INPUT SUB NO. AND PRESS PRINT SWITCH
9 – 44
