Main Sub
Item Content
Adjustment
code code range
26 03 Sets counter
mode.
0-3SIMULATION NO.26- 3
COUNTER MODE SETUP [X] :_
CODE TOTAL COUNT , MAINTE COUNT
0. DOUBLE COUNT , DOUBLE COUNT
1. SINGLE COUNT , DOUBLE COUNT
2. DOUBLE COUNT , SINGLE COUNT
3. SINGLE COUNT , SINGLE COUNT
INPUT SETUP VALUE AND PRESS PRINT SW
[Content] The counter’s count-up mode can be set. The current setting is displayed and a
new setting can be entered.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the sub code
input screen is displayed. If the entered value is not valid, the input field is
cleared and the error buzzer sounds. If any value is not entered, the setting
remains unchanged and the sub code input screen is displayed.
[0-3]: Enters new settings
[C]: Clears the input field.
[PAUSE]: No setting is made and the sub code input screen is displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
06 Sets destination. 1-9SIMULATION NO.26- 6
DESTINATION SETUP [X] :_
[ INCH ]
1.SEC 3.EXTRA
2.SECL
[ AB ]
4.JAPAN 7.SUK
5.KOREA 8.SCA
6.SEEG 9.EXTRA
INPUT SETUP VALUE AND PRESS PRINT SW
[Content] The destination can be set. The current setting is displayed and a new setting can
be entered.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the sub code
input screen is displayed. If the entered value is not valid, the input field is
cleared and the error buzzer sounds. If any value is not entered, the setting
remains unchanged and the sub code input screen is displayed.
[1-9]: Enters new settings
[C]: Clears the input field.
[PAUSE]: No setting is made and the sub code input screen is displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 48
