Main Sub
Item Content
Adjustment
code code range
63 CCD activation
checks.
SIMULATION No.63- _
1.SHADING CORRECTION DATA CHECK
2.SHADING WHITE BOARD CORRECTION
INPUT SUB NO. AND PRESS PRINT SWITCH
01 Checks shading. SIMULATION No.63- 1
SHADING CORRECTION DATA CHECK
BLACK (OFSET) (EVEN/ODD):XXX/XXX
BLACK (EVEN/ODD):XXX/XXX
WHITE (OFSET) (EVEN/ODD):XXX/XXX
WHITE (EVEN/ODD):XXX/XXX
HALF TONE (OFSET) (EVEN/ODD):XXX/XXX
COPY LAMP POWER : XX
[PAUSE]KEY:END DISPLAY
[Content] The previous shading correction data can be checked.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the sub code input screen is
displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
02 Sets shading
white plate
correction value.
SIMULATION No.63- 2
SHADING WHITE BOARD CORRECTION
WITH A WHITE PAPER ON THE ORIGINAL
TABLE, TURN ON THE PRINT SWITCH.
PRINT SWITCH:EXECUTE SIMULATION
• Shading white plate correction in progress
SIMULATION No.63- 2
SHADING WHITE BOARD CORRECTION
CORRECTION VALUE IS SETTING.
[PAUSE]KEY:SUSPENDED ACTIVATION
• Shading white plate correction completed
SIMULATION No.63- 2
SHADING WHITE BOARD CORRECTION
CORRECTION HAS COMPLETED.
CORRECTION VALUE:XXX
[PAUSE]KEY:END DISPLAY
[Content] The value which corrects the difference in CCD output level between the shading
correction white plate and the actual document is set. If the [PRINT] key is pressed
with a sheet of white paper placed on the document table and the document cover
closed, the optical unit moves to read the CCD output of the shading correction
white plate and the CCD output of the white paper. The copier calculates the
correction value from the output levels and stores in memory.
(a) Operation/display
[PRINT]: The correction value is set.
[PAUSE]: The execution of the simulation is stopped and the sub code input screen is
displayed.
[CA]: The execution of the simulation is stopped and simulation is terminated.
9 – 83
