Main Sub
Item Content
Adjustment
code code range
67 02 Centronics port
check.
• Checking in progress
SIMULATION No.67- 2
PRINTER CENTRO PORT CHECK
CHECKING IN PROGRESS
• Checking completed (Example)
SIMULATION No.67- 2
PRINTER CENTRO PORT CHECK
PRINTER CENTRO PORT CHECK OK
[PAUSE]KEY:END DISPLAY
[Content] The Centronics port is checked by connecting a special connector which connects
the Centronics port output and input signal wires to each other, to the Centronics
port of the PRT board. Whether the input signal is turned ON/OFF or not is
checked by turning the output signal ON/OFF. Checking is repeated 10 times. If
there is no error, OK is displayed; if there is any error, NG is displayed.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the sub code input screen is
displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
03 Adjusts
Centronics port
timing.
SIMULATION No.67- 3
PRINTER CENTRO TIMING ADJUSTMENT
CENTRO MODE SETTING VALUE[X]: X
0.STANDARD
1.IBM EPSON
2.RESERVE
3.CLASSIC
2500ns ADJ.VALUE(0~127)[XXX]: XXX
500 ns ADJ.VALUE(0~127)[XXX]: XXX
[|]KEY:MOVE PRINT SW:EXECUTE
[Content] The control signal timing for Centronics port reception can be changed. The cur-
rent Centronics timing is displayed and a new setting can be entered.
The Centronics mode setting is specified by IEEE1284.
0. STANDARD 0-3
1. IBM EPSON
2. RESERVE
3. CLASSIC
The 2500 ns/500 ns adjustment values are adjusted for the minimum delay time
specified by IEEE1284.
2500 ns adjustment value 0-127
500 ns adjustment value 0-127
9 – 86
