Main Sub
Item Content
Adjustment
code code range
67 03 Adjusts
Centronics port
timing.
(a) Operation/display
[PRINT]: If the entered value is valid, the current setting is updated and the screen
changes to the sub code input screen. If the entered value is not valid, the
input field is cleared and the error buzzer sounds.
If any value is not entered, no setting is made and the screen changes to
the sub code input screen.
[0-9]: Enters new settings.
[C]: Clears the input field.
[PAUSE]: No setting is made and the sub code input screen is displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
06 Writes flash font. • Initial screen
SIMULATION No.67- 6
PRINTER FLASH MEMORY FONT DATA
WRITING CHECK
PLEASE SEND FONT DATA FROM PERSONAL
COMPUTER.
• Font data being received
SIMULATION No.67- 6
PRINTER FLASH MEMORY FONT DATA
WRITING CHECK
WRITING IN PROGRESS
• Font write completed (Example)
SIMULATION No.67- 6
PRINTER FLASH MEMORY FONT DATA
WRITING CHECK
FONT DATA WRITING HAS COMPLETED
(1,234,567 BYTE)
[PAUSE]KEY:END DISPLAY
[Content] The contents in the FLASH memory on the PRT board is erased. When the
reception of font data is started, the “font-data-being-received” screen appears.
Font data sent from a personal computer is written in the FLASH memory. After
writing, the “font-data-write-completed” screen appears.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the sub code input screen is
displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 87
