Main Sub
Item Content
Adjustment
code code range
67 07 Compares and
checks flash
font.
• Initial screen
SIMULATION No.67- 7
PRINTER FLASH MEMORY FONT DATA
VERIFYING CHECK
PLEASE SEND FONT DATA FROM PERSONAL
COMPUTER.
• Font data being received
SIMULATION No.67- 7
PRINTER FLASH MEMORY FONT DATA
VERIFYING CHECK
VERIFYING IN PROGRESS
• Font comparison completed (Example)
SIMULATION No.67- 7
PRINTER FLASH MEMORY FONT DATA
VERIFYING CHECK
FONT DATA VERIFYING OK
(1,234,567 BYTE)
[PAUSE]KEY:END DISPLAY
[Content] Font data sent from the personal computer and the contents in the FLASH
memory are compared. If all are the same, OK is displayed; if there is any one
difference between both, NG is displayed.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the sub code input screen is
displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
08 Writes/compares
and checks
flash font.
• Initial screen
SIMULATION No.67- 8
PRINTER FLASH MEMORY FONT DATA
WRITING/VERIFYING CHECK
PLEASE SEND FONT DATA FROM PERSONAL
COMPUTER.
• Font data being received
SIMULATION No.67- 8
PRINTER FLASH MEMORY FONT DATA
WRITING/VERIFYING CHECK
WRITING/VERIFYING IN PROGRESS
9 – 88
