Main Sub
Item Content
Adjustment
code code range
67 08 Writes/compares
and checks
flash font.
• Write/comparison check completed (Example)
SIMULATION No.67- 8
PRINTER FLASH MEMORY FONT DATA
WRITING/VERIFYING CHECK
FONT DATA WRITING/VERIFYING OK
(1,234,567 BYTE)
[PAUSE]KEY:END DISPLAY
[Content] The contents in the FLASH memory on the PRT board are erased. Then,
the font data sent from the personal computer is written in the FLASH
memory and read for comparison. If all are the same, OK is displayed; if
there is any one difference between both, NG is displayed.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the sub code input screen is
displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
09 Flash test. • Test in progress
SIMULATION No.67- 9
PRINTER FLASH MEMORY CHECK
CHECKING IN PROGRESS
• Test completed (Example)
SIMULATION No.67- 9
PRINTER FLASH MEMORY CHECK
PRINTER FLASH MEMORY CHECK OK
[PAUSE]KEY:END DISPLAY
[Content] The contents in the FLASH memory are erased. This test is performed in units of
words (4 bytes) of the CPU. Then, “5555AAAAH” is written in all addresses. The
contents in all the addresses are read in sequence for verification. The contents in
the FLASH memory on the PRT board are erased. Then, “AAAA5555H” is written
in all addresses, and the contents in all the addresses are read in sequence for
verification.
If there is no error, OK is displayed; if there is any error, NG is displayed.
(a) Operation/display
[PAUSE]: The execution of the simulation is stopped and the sub code input screen is
displayed.
[CA]: The execution of the simulation is stopped and the simulation is terminated.
9 – 89
