AR-203E/5420/M200/M201 SIMULATION, TROUBLE CODES 10 - 4
02 02 SPF/RSPF sensor status
display (Only the AR-203E/
M200/M201 with the
SPF/RSPF installed)
[Function]
The ON/OFF status of the SPF/RSPF sensors can be checked with the LCD/LED.
When a sensor is ON, the sensor name is displayed on the LCD/LED.
[Operation] (AR-M200/M201)
03 SPF/RSPF Motor ON
(Only the AR-203E/M200/
M201 with the SPF/RSPF
installed)
[Function]
When [OK]/[ENTER]/[START] key is pressed, the motor rotates for 10sec at the speed corre-
sponding to the set magnification ratio.
[Operation] (AR-M200/M201)
The operation is similar to simulation 01-01.
06 Resist clutch ON (SPF)
(AR-203E only)
When the [START] key is pressed, the SPF resist clutch (SRRC) repeats ON (500 ms) and OFF
(500 ms) 20 times.
08 RSPF paper feed solenoid
operation check
(Only the AR-M200/M201
with the RSPF installed)
[Function]
The RSPF paper feed solenoid (SPUS) repeats ON for 500ms and OFF for 500ms 20 times by
the use of the solenoid drive control Bios.
[Operation]
09 RSPF reverse solenoid
operation check
(Only the AR-M200/M201
with the RSPF installed)
[Function]
The RSPF reverse solenoid (SPFS) repeats ON for 500ms and OFF for 500ms 20 times by the
use of the solenoid drive control Bios.
[Operation]
03 03 Shifter operation check
(AR-M200/M201)
[Function]
The shifter is moved back and forth in four reciprocations.
[Operation]
Main
code
Sub
code
Contents Details of function/operation
Sensor
Display item
(AR-M200/M201)
Display item
(AR-203E)
Document set sensor SPID TD cartridge replacement required
lamp
RSPF document transport sensor SPPD Misfeed lamp
RSPF paper feed cover open/close
sensor
SDSW —
RSPF paper exit sensor SPOD —
1) Initial display 2) When the sensor is ON:
02-02 SPF SENSOR
02-02 SPF SENSOR
SPID SPPD SDSW SPOD
1) Initial display
02-08 SPF SPUS CHK
EXECUTING...
1) Initial display
02-09 RSPF SPFS CHK
EXECUTING...
1) Initial display
03-03 SHIFTER CHK
EXECUTING...
