Sharp AX-1100R Service Manual

AX1100(R)
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[1] OVEN PARTS
ELECTRIC PARTS
AM RMOTDA280WRZZ AQ Turntable Motor (Antenna motor)
!
C RC-QZA352WRZZ AS HV Capacitor
DM RMOTDA280WRZZ AQ Intake Damper Motor
EH CHET-A024WRKZ BC Engine Unit Assembly(Engine heating element)
F1 QFS-BA009WRE0 AH Fuse 20A (Special fuse)
F1 QFS-BA012WRZZ AG Fuse 20A (Special fuse) (Interchangeable)
FM RMOTEA478WRZZ AS Fan Motor
!
*
MG RV-MZA347WRZZ BH Magnetron
OL RLMPTA101WRZZ AM Oven Lamp
OL RLMPTA088WRZZ AN Oven Lamp (Interchangeable)
OL RLMPTA083WRZZ AM Oven Lamp (Interchangeable)
PM FMOT-A044WRKZ AZ Tube Pump Assembly
PM-1 RMOTDA280WRZZ AQ PM : Pump motor (Turntable Motor)
PM-2 PTUBXA080WREZ AG Water Tube
PM-3 PTUBXA081WREZ AH Pump Tube L
PM-4 XHPS740P08K00 AB Screw : 4mm x 8mm
PM-5 XEPS740P08000 AB Screw : 4mm x 8mm
SW1 QSW-MA087WRE0 AF Monitored Interlock Switch
SW1 QSW-MA146WRZZ AM Monitored Interlock Switch (Interchangeable)
SW2 QSW-MA086WRE0 AF Monitor Switch
SW2 QSW-MA148WRZZ AF Monitor Switch (Interchangeable)
SW3 QSW-MA085WRE0 AF Door Sensing Switch
SW3 QSW-MA147WRZZ AG Door Sensing Switch (Interchangeable)
SW4 QSW-MA086WRE0 AF Intake Damper Switch
SW4 QSW-MA132WRE0 AH Intake Damper Switch (Interchangeable)
SW5 QSW-MA085WRE0 AF Antenna Switch
SW5 QSW-MA117WRE0 AE Antenna Switch (Interchangeable)
SW5 QSW-MA147WRZZ AG Antenna Switch (Interchangeable)
!
T RTRN-A796WRZZ BG High Voltage transformer
TC1 RTHM-A168WRZZ AH Thermal Cut Out (MG thermal cut-out)
TC2 RTHM-A149WRZZ AK Oven thermal cut-out
TC2 RTHM-A144WRZZ AF Oven thermal cut-out (Interchangeable)
TC3 RTHM-A149WRZZ AK SH Thermostat (Engine thermal cut-out)
TC3 RTHM-A144WRZZ AF SH Thermostat (Engine thermal cut-out) (Interchangeable)
TH1 FH-HZA100WREZ AN Thermistor (Engine)
TH2 FH-HZA099WREZ AN Thermistor (Grill)
1-1-1 QFS-CA024WRE0 AH F2: Fuse F8A
1-1 FPWBFA309WRE4 AT Noise Filter
1-2 QACCVA004URE3 AT Power Supply Cord
!
1-3 FH-DZA135WRZZ AR HV Rectifier Assembly
1-4 FW-VZC309WREZ BB Main Harness
CABINET PARTS
7-1 GCABDA170WRWZ AV Back Plate
7-2 GCABUB219WRPZ BE Outer Case Cabinet [AX1100(IN)]
7-2 GCABUB256WRPZ AZ Outer Case Cabinet [AX1100(R)]
7-3 GDAI-A476WRWZ AW Bottom Plate
7-4 GDAI-A478WRWZ AX Bottom Plate Cover
MECHANICAL PARTS
8-1 LANGKB469WRPZ AD Engine Thermo Angle
* 8-2 Oven Assembly
8-3 MLEVPA299WRFZ AG Switch Lever
* 8-4 PHOK-A172WRFZ AK Latch Hook
8-5 LBNDKA172WRPZ AM HV Capacitor Band
8-6 LANGTA529WRPZ AG Air Damper Motor Ag
8-7 MCAMPA188WRFZ AK Air Damper Cam
8-8 NSFT-A007WREZ AF Damper Shaft
8-9 PDMP-A004WRPZ AG Air Damper
8-10 PDUC-B197WRPZ AL Air Duct
8-11 PPAC-A164WREZ AH Air Damper Packing
8-12 MJNTPA020WRFZ AH Steam Ex Joint
8-13 PDUC-B201WRFZ AH Steam Ex Duct
8-14 NFANJA038WRE0 AG Fan Blade
8-15 LANGKB126WRPZ AK TT Motor Mount Angle
8-16 FTNK-A033WRKZ AZ Tank Assembly (Water tank) [AX1100(IN)]
8-16 FTNK-A034WRKZ BA Tank Assembly (Water tank) [AX1100(R)]
8-16-1 FDEC-A005WRKZ AU Tank Front Assembly [AX1100(IN)]
8-16-1 FDEC-A006WRKZ AV Tank Front Assembly [AX1100(R)]
8-16-2 PCOVPA539WRFZ AG Tank Lid
8-16-3 PPAC-A018WREZ AC Tank Packing
8-17 MJNTPA019WRFZ AF Tank Joint
8-18 MSPRPA108WREZ AF Tank Spring
8-19 PCOVPA537WRFZ AN Tank Cover
8-20 GCUPPA029WRFZ AN Dew Tray (Drip tray)
8-21 GLEGPA074WRE0 AC
Leg
8-22 LANG-A146WRPZ AH Separate Angle
8-23 LANGTA535WRPZ AG Lamp Glass To Ag
8-24 LANGTA536WRPZ AG Chassis Support
8-25 LBND-A033WREZ AC Hose Band
8-26 LBND-A047WREZ AF Hose Band
8-27 LHLDKA008WRF1 AF P-Clip
8-28 GCOVHA557WRPZ AF Back plate cover
8-29 LHLDWA064WREZ AF Wire Holder
