Sharp AX-1100R Service Manual

AX1100(R)
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
8-30 MHNG-A648WRMZ AH Upper Hinge
8-31 MHNG-A651WRMZ AG Lower Hinge
8-32 MJNTPA018WRPZ AF Tube
8-33 PCUS-A276WREZ AC Tank Cover Cushion
8-34 LBND-A029WREZ AF Pin band
8-35 PTUBXA074WREZ AK Joint Tube
8-36 PCUS-A298WREZ AF Top Cushion
8-37 PDUC-B203WRPZ AH Fan Duct
8-38 PFPF-A316WREZ AP Thermal Insulation U
8-39 PGID-A109WRFZ AF Dew Tray Guide Left
8-40 PGID-A110WRFZ AF Dew Tray Guide Right
8-41 PGIDMA023WRFZ AH Back Dew Guide
8-42 PTUBXA082WREZ AK Steam Ex Tube
8-43 PGLSPA743WREZ AG Lamp Glass
8-44 PPAC-A133WREZ AD Engine Packing B
8-45 PPAC-A166WREZ AH Lamp Packing
8-46 PSLDHA311WRPZ AL Thermal Cover Right
8-47 PCUSGA820WRPZ Cushion
8-48 PCUSGA667WRPZ AE Cushion
8-49 TCAUSA017WRRZ AL High Temperature caution
8-50 LANGTA550WRPZ Support angle
8-51 Oven thermo angle
8-52 PSHEPB504WREZ AF Insulator sheet
8-53 PPAC-A090WREZ AF Thermistor packing
SCREWS, WASHERS AND NUTS
9-1 XCBS730P08000 AB Screw; 3mm x 35mm
9-2 XBTWW40P06000 AA Screw; 4mm x 6mm
9-3 XCTS740P08000 AC Screw; 4mm x 8mm
9-4 XBPS740P35000 AD Screw; 4mm x 35mm
9-5 XCPS730P14000 AB Screw; 3mm x 14mm
9-6 XHPS740P08K00 AB Screw; 4mm x 8mm
9-7 XHBS730P08000 AC Screw; 3mm x 8mm
9-8 XOTS740P08000 AA Screw; 4mm x 8mm [AX1100(IN)]
9-8 XOTS840P08000 AB Screw; 4mm x 8mm [AX1100(R)]
9-9 XOTS740P08000 AA
Screw; 4mm x 8mm
9-10 XOTS740P12RV0 AD Screw; 4mm x 12mm
9-11 XOTS740P06000 AA Screw; 4mm x 6mm
9-12 XNES740-32000 AC Nut; 4mm x 3.2mm
9-13 XNEUW40-32000 AA Nut; 3mm x 3.2mm
9-14 XFPWW30P06K00 AC Screw; 3mm x 6mm
9-15 LX-BZA148WREZ AC Special Screw
9-16 LX-CZ0052WRE0 AA Special Screw
9-17 XBTUW40P06000 AA Screw; 4mm x 6mm
9-19 XCPS740P08000 AB Screw; 4mm x 8mm
9-20 XHTS740P08RV0 AG Screw; 4mm x 8mm
9-21 XEPS740P10000 AA Screw; 4mm x 10mm
9-22 XETS740P08000 AA Screw; 4mm x 8mm
9-23 XHPS740P08000 AB Screw; 4mm x 8mm
9-24 XHPS740P06K00 AC Screw; 4mm x 6mm
9-25 XEPS730P10X00 AA Screw; 3mm x 10mm
9-26 XHPS740P12KS0 AD Screw; 4mm x 12mm
9-27 XOTWW40P08000 AB Screw; 4mm x 8mm
9-28 XHBS730P06000 AC Screw; 3mm x 6mm
[1] OVEN PARTS
