Sharp AY-AP9KR User Manual

IT-2
NOMI DEI COMPONENTI
UNITA' INTERNA
1
Entrata (dell’aria)
2
Pannello aperto
3
Filtri dell’aria
4
Tasto AUX
5
Finestra di ricezione
6
Cavo d’alimentazione
7
Defl ettori di regolazione verticale
8
Defl ettori di regolazione orizzontale
9
Uscita (dell’aria)
0
Spia PLASMACLUSTER (blu)
q
Spia di FUNZIONAMENTO (rossa )
w
Spia TIMER (arancione )
e
Spia TURBO (verde
)
UNITA' ESTERNA
r
Entrata (dell’aria)
t
Tubo refrigerante e cavo di intercon-
nessione
y
Tubo di drenaggio
u
Uscita (dell’aria)
NOTE:
Le unità effettive potrebbero differire leg-
germente da quelle illustrate sopra.
1
2
3
4
5
6
7
8
9
0
q
w
e
r
t
y
u
AE-A18KR
AE-A24KR
AY-AP18KR
AY-AP24KR
AY-AP9KR
AY-AP12KR
AE-A9KR
AE-A12KR

Sharp AY-AP9KR Specifications

General

Type	Split system
Multi-split	Yes
Product color	White
Hose length (max)	10 m
Refrigerating medium	R410A
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (nominal)	820 W
Cooling energy efficiency (EER, W/W)	3.22
Heating energy efficiency (COP, W/W)	3.63
Seasonal efficiency rating (cooling) (SEER)	-
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	800 W
AC input voltage	220-240 V
AC input frequency	50 Hz
Design load (cooling)	- kW
Energy efficiency class (cooling)	A
Annual energy consumption (cooling)	410 kWh
Hourly energy consumption (cooling)	3.7 kWh
Hourly energy consumption (heating)	3.6 kWh
Annual energy consumption (heating) (Warmer heating season)	- kWh
Indoor unit type	Wall-mountable
Indoor unit depth	198 mm
Indoor unit width	860 mm
Indoor unit height	292 mm
Indoor unit weight	8500 g
Indoor units quantity	1
Indoor unit noise level (high speed)	54 dB
Outdoor unit depth	250 mm
Outdoor unit width	730 mm
Outdoor unit height	540 mm
Outdoor unit weight	27000 g
Outdoor unit noise level	59 dB
