PT-7
PORTUGUÊS
Nesta operação, a ventoínha do ar condicionado
funciona a velocidade “super elevada” com uma
regulação de temperatura de 15°C nos modos
FRIO e SECAR e 32°C no modo CALOR para ar-
refecer ou aquecer rapidamente a divisão.
1
Durante o funcionamento, prima a tecla
FLUXO TURBO.
O telecomando irá exibir o símbolo “ ”.
O mostrador da temperatura desligar-se-á.
A lâmpada verde TURBO (
)
acender-se-á.
PARA DESACTIVAR
Prima novamente a tecla FLUXO TURBO.
A lâmpada laranja de TEMPORIZADOR ( )
na unidade desligar-se-á.
NOTA:
Não pode de nir a temperatura nem a velocidade
da ventoinha durante a operação do TURBO.
Para desligar a lâmpada TURBO, prima a tecla
DISPLAY.
Após a unidade funcionar durante 30 minutos em
modo TURBO, a regulação da ventoínha passa à
velocidade "RÁPIDO" e a temperatura ca de ni-
da em 18ºC nos modos FRIO e SECAR.
OPERAÇÃO TURBO
1
No modo FRIO ou SECAR, as palhetas verticais
são ajustadas para que o ar saia obliquamente
para cima em direcção ao tecto evitando exposi-
ção directa ao uxo de ar.
No modo CALOR, as palhetas verticais são ajus-
tadas para que o ar saia na vertical em direcção
ao solo.
1
Durante o funcionamento, prima a tecla
FLUXO COANDA.
O telecomando irá exibir o símbolo “ ”.
PARA DESACTIVAR
Prima novamente a tecla FLUXO COANDA.
NOTA:
Se quiser desfrutar do FLUXO COANDA no modo
TURBO, prima a tecla FLUXO COANDA durante
o funcionamento TURBO.
OPERAÇÃO COANDA
1

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sharp AY-AP9KR and is the answer not in the manual?

Sharp AY-AP9KR Specifications

General IconGeneral
TypeSplit system
Multi-splitYes
Product colorWhite
Hose length (max)10 m
Refrigerating mediumR410A
Air conditioner functionsCooling, Heating
Cooling capacity in watts (nominal)820 W
Cooling energy efficiency (EER, W/W)3.22
Heating energy efficiency (COP, W/W)3.63
Seasonal efficiency rating (cooling) (SEER)-
Heating capacity in watts (nominal) (Warmer heating season)- W
Heating capacity in watts (nominal) (Average heating season)800 W
AC input voltage220-240 V
AC input frequency50 Hz
Design load (cooling)- kW
Energy efficiency class (cooling)A
Annual energy consumption (cooling)410 kWh
Hourly energy consumption (cooling)3.7 kWh
Hourly energy consumption (heating)3.6 kWh
Annual energy consumption (heating) (Warmer heating season)- kWh
Indoor unit typeWall-mountable
Indoor unit depth198 mm
Indoor unit width860 mm
Indoor unit height292 mm
Indoor unit weight8500 g
Indoor units quantity1
Indoor unit noise level (high speed)54 dB
Outdoor unit depth250 mm
Outdoor unit width730 mm
Outdoor unit height540 mm
Outdoor unit weight27000 g
Outdoor unit noise level59 dB
