Sharp AY-X36RU - Part Names

EN-4
INDOOR UNIT
1 Inlet (Air)
2 Open Panel
3 Air Filter
4 AUTO(AUX) Button
5 Vertical Airow Louver
6 Horizontal Airow Louver
7 Outlet (Air)
8 Receiver Window
9 DRY Lamp
10 OPERATION Lamp
ON: Green
OFF: Red
11 TEMPERATURE Indicator
12 COOL Lamp
13 HEAT Lamp
14 Inlet (Air)
15 Refrigerant Pipe and Interconnecting
Cord
16 Drainage Hose
17 Outlet (Air)
NOTE:
Actual units might vary slightly from
those shown above.
OUTDOOR UNIT
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
PART NAMES
