2.2. Printed wiring board
To Reactor
(Gray)
From Terminal Board
(Themal fuse)
To Terminal Board
(N)(Blue)
From Compressor(R)
(Orange)
From Compressor(S)
(White)
From Compressor(C)
(Red)
From Fan
Motor
From Thermistor
To Reactor
(Gray)
To Terminal Board
(1)(Brown)
To Terminal Board
(3)(Red)
To Control Box
(Green/Yellow)
From heatsink
TEMP fuse
To PWB
BT6(Gray)
