[4] ELECTRICAL PARTS
1. Indoor unit
2. Outdoor Unit
DESCRIPTION MODEL REMARKS
Indoor fan motor MLA521 AC Motor
Indoor fan motor capacitor DS401155BLSA RC-HZA512JBZZ (400V-1.5μF)
Transformer VRK4119–290mA RTRNPA030JBZZ
Fu1 – QFS-IA001KKZZ (250V, 2.5A)
DESCRIPTION MODEL REMARKS
Compressor 43A23YBM&FJKE D.C. brush-less motor
Outdoor fan motor MLB452 AC Motor(AE-X12LSR)
Outdoor fan motor MLB453 AC Motor(AE-X9LSR)
Outdoor fan motor capacitor DS441155XLTD 440V, 1.5μF (AE-X9LSR) on PWB
DS441205XLTC 440V, 2.0μF (AE-X12LSR) on PWB
Fu3 – QFS-GA063JBZZ (250V, 2A)
Fu2 – QFS-GA062JBZZ (250V, 3.15A)
Fu1 – QFS-GA065JBZZ (250V, 20A)
Fu5 – QFS-GA066JBZZ (250V, 15A)
