AYX P9L SR
Service Manual
CHAPTER 1. SPECIFICATION
[1] SPECIFICATION
1. AY-XP9LSR – AE-X9LSR
NOTE: The conditions of star ”I” marked item are “ISO5151:1994(E)”, condition T1’.
MODEL INDOOR UNIT OUTDOOR UNIT
ITEMS AY-XP9LSR AE-X9LSR
Rated cooling capacity (Min– Max.) kW 2.5 (0.9 - 3.0)
Rated heating capacity (Min–Max.) kW 2.9 (0.9 - 3.7)
Moisture removal (at cooling) Liters/h 0.8
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage V 220-240
Rated current I
(Min - Max.)
Cool A 4.0 (1.3 - 5.4 )
Heat A 4.0( 1.2 - 5.9 )
Rated input I
(Min - Max.)
Cool W 770 (240- 1100)
Heat W 780 (220 - 1200)
Power factor I Cool % 84
Heat % 85
Compressor Type Hermetically sealed rotary type
Model 43A23YBM&FJKE
Oil charge 370cc (Zegles RB68EP)
Refrigerant system Evaporator Louver Fin and Grooved tube type
Condenser Corrugate Fin and Grooved tube type
Control Capillary tube
Refrigerant (R410A) 690g
De-lce system Micro computer controled reversed systems
Noise level
(at cooling)
High dB(A) 37 45
Low dB(A) 31 –
Soft dB(A) 23 –
Fan system
Drive Direct drive
Air flow quantity
(at cooling)
High m3/min. 9.1 26.4
Low m3/min. 7.4 –
Soft m3/min. 4.7 –
Fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 3/8", 1/4"
Drain piping mm O.D φ16
Others
Safety device Compressor: Thermal protector
Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 860 730
Height mm 292 540
Depth mm 205 250
Net weight kg 8.5 30
