2. AY-XP12LSR – AE-X12LSR
NOTE: The conditions of star ”I” marked item are “ISO5151:1994(E)”, condition T1’.
MODEL INDOOR UNIT OUTDOOR UNIT
ITEMS AY-XP12LSR AE-X12LSR
Rated cooling capacity (Min– Max.) kW 3.5 (0.9 - 3.8)
Rated heating capacity (Min–Max.) kW 4.0 (0.9 - 4.7)
Moisture removal (at cooling) Liters/h 1.2
Electrical data
Phase Single
Rated frequency Hz 50
Rated voltage V 220-240
Rated current I
(Min - Max.)
Cool A 5.0 (1.3 - 6.0 )
Heat A 5.0(1.2 - 7.1 )
Rated input I
(Min - Max.)
Cool W 1080 (240- 1250)
Heat W 1075 (220 - 1470)
Power factor I Cool % 94
Heat % 93
Compressor Type Hermetically sealed rotary type
Model 43A23YBM&FJKE
Oil charge 370cc (Zegles RB68EP)
Refrigerant system Evaporator Louver Fin and Grooved tube type
Condenser Corrugate Fin and Grooved tube type
Control Capillary tube
Refrigerant (R410A) 970g
De-lce system Micro computer controled reversed systems
Noise level
(at cooling)
High dB(A) 40 48
Low dB(A) 33 –
Soft dB(A) 23 –
Fan system
Drive Direct drive
Air flow quantity
(at cooling)
High m3/min. 11.2 33.4
Low m3/min. 8.7 –
Soft m3/min. 5.5 –
Fan Cross flow fan Propeller fan
Connections
Refrigerant coupling Flare type
Refrigerant tube size Gas, Liquid 1/2", 1/4"
Drain piping mm O.D φ16
Others
Safety device Compressor: Thermal protector
Fan motors: Thermal fuse
Fuse, Micro computer control
Air filters Polypropylene net (Washable)
Net dimensions Width mm 860 730
Height mm 292 540
Depth mm 205 250
Net weight kg 9 32
