Sharp CD-BA150 Service Manual

254 92LPT0311101 J AB Lever,Clamp
255 92LPT0311102 J AC Lever,Disc
256 92LPT0312005 J Gear,Cam
257 92LPT0320201 J AE Support,Stabilizer
258 92LPT0330301 J AU Chassis,Loading
259 92LPT0330803 J AK CD,Chassis
260 92LPT0331003 J AT Chassis,Slide
262 92LSP0304303 J Spring,Stopper
263 92LSP0304305 J AB Spring,Lock
264 92LSP0304306 J Spring,Lock Gear
267 LANGK0184AWFW J AG Bracket,Tuner PWB
268 KMECB0011AWZZ J BH Tape Mechanism Ass’y
269 PSHEZ0069AWZZ J Bracket,PWB Sheet
270(SW1) SWMPU10780MLB J Switch,Push Type [Open/Close]
271(SW2) SWMPU11470MLB J Switch,Push Type [Clamp]
272(SW3) SWMPU11470MLB J Switch,Push Type [Disc Number]
273(M3) 92LTWMEN7E6Y J Motor with Worm Pulley
[T/T Up/Down Loading]
601 XBBSD20P04000 J AA Screw,ø2×4mm
604 XEBSF30P12000 J AA Screw,ø3×12mm
605 XESSD30P10000 J AA Screw,ø3×10mm
606 XHBSD26P04000 J AA Screw,ø2.6×4mm
607 XJBSD30P12000 J AA Screw,ø3×12mm
608 XJBSD30P10000 J AA Screw,ø3×10mm
609 XJBSD30P14000 J AA Screw,ø3×14mm
610 XJBSF30P10000 J AA Screw,ø3×10mm
611 XJSSD30P10000 J AA Screw,ø3×10mm
612 LX-HZ0009AWFD J AC Screw,Special
613 LX-HZ0169AFFD J AA Screw,Special
614 LX-JZ0010AFFD J AA Screw,Special
615 XEBSD30P10000 J AA Screw,ø3×10mm
616 LX-BZ2222AXZZ J Screw,Special
617 LX-JZ0004AWFD J AA Screw,ø3×12mm
618 92LSC0308MBZI J AB Screw,ø3×8mm
619 92LSC0308RBZI J Screw,ø3×8mm
PACKING PARTS (Except for U.S.A.)
SPAKA0235AWZZ J Packing Add.,Left/Right
SPAKC0920AWZZ J Packing Case [For U.S.A.]
SPAKC0921AWZZ J Packing Case [For Canada]
SPAKC0922AWZZ J Packing Case
[For Central America/Mexico]
SPAKP0013AWZZ1 J AC Polyethylene Bag,Unit
92LBAG1460C1 J AB Polyethylene Bag,Accessories
92L411-0075 J Polyethylene Bag,Speaker
92L412-0133 J Packing Add.,Speaker
92L416-0068 J Layer Pad
ACCESSORIES (Except for U.S.A.)
QACCD0015AWOO J AC Power Supply Cord
[For Canada]
QACCD0020AWZZ J AN AC Power Supply Cord
[Except for Canada]
QANTL0007AWZZ J AK AM/FM Loop Antenna
TINSE0279AWZZ J AD Operation Manual
[For U.S.A.]
TINSK0097AWZZ J AF Operation Manual [For Canada]
TINSZ0501AWZZ J Operation Manual
[For Central America/Mexico]
TINSZ0502AWZZ J AD Quick Guide [U.S.A.Only]
TLABR1088AWZZ J AB Label,Bar Code
TLABZ0669AWZZ J Label,Feature,Tape 1
TLABZ0670AWZZ J Label,Feature,Tape 2
RRMCG0219AWSA J AR Remote Control
GFTAB1022AWSB J AK Battery Lid,Remote Control
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1~4 92LPWB3283MANS J –– Main/Display/Headphones/
Socket (Combined Ass’y)
PWB-B 92LPWB3303CDUS J –– CD Servo
PWB-C QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-D ———— –– Tape Mechanism
PWB-E 92LPC99C017 J CD Loading Motor (PWB Only)
CABINET PARTS
201 92LCAB3283AASY J Front Cabinet Ass’y
201- 1 ———— –– Front Panel
(Not Replacement Item)
201- 2 GDORF0074AWSA J AE Holder,Cassette,Tape 1
201- 3 GDORF0075AWSA J AE Holder,Cassette,Tape 2
201- 4 GCOVA1251AWSA J AH Cover,Cassette,Tape 1
201- 5 GCOVA1252AWSA J AH Cover,Cassette,Tape 2
201- 6 HDECQ0521AWSA J AD Panel,Cassette,Tape 1
201- 7 HDECQ0522AWSA J AD Panel,Cassette,Tape 2
201- 8 HDECQ0520AWSA J AK Panel,Amp.
201-10 JKNBZ0649AWSA J AF Button,Volume
201-11 JKNBZ0648AWSA J AG Button,Center Operation
201-12 JKNBZ0657AWSA J AF Button,Power/Clock
201-13 JKNBZ0658AWSA J AF Button,Function,A
201-14 JKNBZ0659AWSA J AF Button,Function,B
201-15 JKNBZ0660AWSA J AF Button,Tuning
201-16 JKNBZ0661AWSA J AE Button,Dimmer
201-20 GCOVA1258AWSA J AB Cover,LED,C
201-21 MLIFP0008AWZZ J AD Damper
201-22 MSPRD0092AWFJ J AB Spring,Cassette,Tape 1
201-23 MSPRD0093AWFJ J AB Spring,Cassette,Tape 2
201-24 92LBADGE1671A J AC Badge,SHARP
201-25 JKNBZ0650AWSA J AF Button,Disc/X-BASS
202 92LCAB3283BASY J Side Panel Ass’y,Left
202- 1 ———— –– Side Panel,Left
(Not Replacement Item)
202- 2 PCUSG0022AWZZ J AB Cushion,Leg
203 92LCAB3283CASY J Side Panel Ass’y,Right
203- 1 ———— –– Side Panel,Right
(Not Replacement Item)
203- 2 PCUSG0022AWZZ J AB Cushion,Leg
204 92LCOV3303AASY J CD Tray Cover Ass’y
204- 1 ———— –– Cover,CD Tray
(Not Replacement Item)
204- 2 GCOVA1254AWSA J AE Cover,CD Tray Panel,Left
204- 3 GCOVA1255AWSA J AE Cover,CD Tray Panel,Right
205 GCAB-1184AWSA J AP Top Cabinet
206 GITAR0539AWSA J AH Rear Panel
[For U.S.A.]
206 GITAR0540AWSA J Rear Panel [For Canada]
206 GITAR0541AWSA J Rear Panel
[For Central America/Mexico]
208 LANGK0110AWFW1J AD Support,Cassette Lock,Tape 1
209 LANGK0111AWFW1J AD Support,Cassette Lock,Tape 2
210 LANGK0192AWFW J AD Bracket,Fan Support
213 LCHSM0094AWFW J AP Main Chassis
214 LHLDZ1241AWZZ J AE Holder,FL Display
219 MLOKC0003AWZZ J AD Lock Lever,Cassette,Tape 1
220 MLOKC0004AWZZ J AD Lock Lever,Cassette,Tape 2
221 MSPRD0109AWFJ J AB Spring,Cassette Lock,Tape 1
222 MSPRD0110AWFJ J AB Spring,Cassette Lock,Tape 2
223 NFANP0001AWZZ J AD Rotary Fan
224 92LPT0331105 J AM Table Loading
225 PCUSG0022AWZZ J AB Cushion,Leg
226 PRDAR0148AWFW J AR Heat Sink,Main
230 QCNWN1615AWZZ J AC Lug Wire
! 231 QFSHD0001AWZZ J AB Holder,Fuse
232 92LBE241414 J AD Belt
233 92LCSPR1431C J AA Spring,Ring
234 92LEVA0330702 J Velvet Carpet,Chassis
235 92LMAG0104302 J Magnet
236 92LMT0304302 J Plate,Metal
237 92LNBAND1318A J AA Nylon Band,80mm
238 92LNM0305401 J Velvet Carpet
239 92LPT0303002 J AB Roller
240 92LPT0304303 J AB Lever,Stop
241 92LPT0304304 J Stopper
242 92LPT0304305 J AE Lever,Lock
243 92LPT0304306 J Stabilizer
244 92LPT0304307 J AC Support,Cam
245 92LPT0304308 J Lock Gear Pin
246 92LPT0304309 J Cap,Pulley Stopper
247 92LPT0305413 J Cam Gear Lower
248 92LPT0309506 J AD Gear,Turntable Drive
249 92LPT0309507 J AD Gear,Open/Close Drive
250 92LPT0309508 J AD Gear,Planet
251 92LPT0309509 J AD Gear,Drive
252 92LPT0309510 J AE Gear,Pulley
253 92LPT0309511 J AD Gear,Middle
PARTS CODE
PRICE
RANK
DESCRIPTIONNO.
– 5 –
PRICE
RANK
DESCRIPTIONNO.
PARTS CODE
CD-BA150
