Sharp CD-BK250W - Page 62

PRICE
RANK
DESCRIPTION
NO.
PARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BK250W/CD-BK2600W/CD-BK270W
P.W.B. ASSEMBLY (Not Replacement Item)
1 PWB-A1~3 92LPWB3563MANS J — Main/Power/Transformer
(Combined Ass’y)
[For CD-BK250W/CD-BK2600W]
1 PWB-A1~3 92LPWB3747MANS J — Main/Power/Transformer
(Combined Ass’y)
[For CD-BK270W]
PWB-B1,2 92LPWB3563DPLS J — Display/Headphones
(Combined Ass’y)
[For CD-BK250W/CD-BK2600W]
PWB-C 92LPWB3563CDUS J — CD Servo
PWB-D 92PF567-649 J — Tape Mechanism
PWB-E 92LPC99C017 J AE CD Loading Motor (PWB Only)
PWB-F QPWBF0027AWZZ J AD CD Motor (PWB Only)
PWB-G1 92LPWB3553MICS J — Mic
[For CD-BK250W/CD-BK2600W]
PWB-G1,2 92LPWB3747MICS J — Mic/Surround Speaker
(Combined Ass’y)
[For CD-BK270W]
OTHER SERVICE PART
UDSKA0004AFZZ J AZ CD Pickup Lens Cleaner
– 7 –
CP-BK250/CP-BK2600/CP-BK270
SPEAKER BOX PARTS
901 GBOXS6002AWSB J BB Speaker Box Ass’y
[For CP-BK250/CP-BK270]
901 GBOXS6003AWSB J BB Speaker Box Ass’y
[For CP-BK2600]
901-1 QCNWN1833AWZZ J Speaker Cord Ass’y
(With Capacitor C1,2)
902 CWAKP1045AWSF J Net Frame Ass’y
[For CP-BK250/CP-BK270]
902 CWAKP1045AWSE J Net Frame Ass’y
[For CP-BK2600]
903 HPNLS1020AWSA J AW Front Panel
[For CP-BK250/CP-BK270]
903 HPNLS1020AWSB J AW Front Panel [For CP-BK2600]
904 LHLDZ8001AWSA J AD Catching Holder
[For CP-BK250/CP-BK270]
904 LHLDZ8001AWSB J AD Catching Holder [For CP-BK2600]
905 PCUSS0048AWZZ J Port Cushion
906 PCUSG0022AWZZ J AB Foot Cushion
907 TSPC-0836AWZZ J Label,Specifications
[For CP-BK250]
907 TSPC-0840AWZZ J Label,Specifications
[For CP-BK2600]
907 TSPC-0906AWZZ J Label,Specifications
[For CP-BK270]
908 XJBSD40P12000 J AA Screw,ø4×12mm
909 XJBSD30P10000 J AA Screw,ø3×10mm
SP1,2 RSPA10007AW6W J AX Woofer
[For CP-BK250/CP-BK2600]
SP1,2 RSPA10025AW8W J Woofer [For CP-BK270]
SP3,4 RSPA00008AW6T J AP Tweeter
[For CP-BK250/CP-BK2600]
SP3,4 RSPA00018AW8T J Tweeter [For CP-BK270]
PACKING PARTS
SPAKA0301AWZZ J AK Packing Add.
SSAKH0051AWZZ J AC Polyethylene Bag,Speaker
GBOXS0070AWM1 (CD-BK270W Only)
SURROUND SPEAKER BOX PARTS
901 CWAKP1055AWM3 J Net Frame Ass’y
902 GCAB-1208AWSA J Bottom Cabinet
903 TLABM0128AWZZ J Label,Parts Code
904 XJBSD30P140000 J Screw,ø3×14mm
SP1,2 RSPA10034AWWP J Speaker
