Sharp CD-BK270W Service Manual

NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-BK250W/CD-BK2600W/CD-BK270W
1 222 QACCE0010AW00 J AK AC Power Supply Cord
1 222 QACCJ0007AW00 J AK AC Power Supply Cord
1 222 QACCL0005AW00 J AN AC Power Supply Cord
223 QCNWN1844AWZZ J AC Lug Wire
1 224 QFSHD0001AWZZ J AB Holder,Fuse
225 92LBE231616 J AD Belt
226 92LCSPR1431C J AA Spring,Ring
227 92LEVA0330702 J AD Velvet Carpet,Chassis
228 92LMAG0104302 J AE Magnet
229 92LMT0304302 J AB Plate,Metal
230 92LNBAND1318A J AA Nylon Band,80mm
231 92LNM0305401 J AB Velvet Carpet
232 92LPT0303002 J AB Roller
233 92LPT0304303 J AB Lever,Stop
234 92LPT0304304 J AB Stopper
235 92LPT0304305 J AE Lever,Lock
236 92LPT0304306 J AG Stabilizer
237 92LPT0304307 J AC Support,Cam
238 92LPT0304308 J AB Lock Gear Pin
239 92LPT0304309 J AB Cap,Pulley Stopper
240 92LPT0305413 J AG Cam Gear Lower
241 92LPT0309506 J AD Gear,Turntable Drive
242 92LPT0309507 J AD Gear,Open/Close Drive
243 92LPT0309508 J AD Gear,Planet
244 92LPT0309509 J AD Gear,Drive
245 92LPT0309510 J AE Gear,Pulley
246 92LPT0309511 J AD Gear,Middle
247 92LPT0311101 J AB Lever,Clamp
248 92LPT0311102 J AC Lever,Disc
249 92LPT0312005 J AL Gear,Cam
250 92LPT0320201 J AE Support,Stabilizer
251 92LPT0330301 J AU Chassis,Loading
252 92LPT0330803 J AK CD,Chassis
253 92LPT0331003 J AT Chassis,Slide
254 92LPT0331105 J AM Turntable
255 92LSP0304303 J AB Spring,Stopper
256 92LSP0304305 J AB Spring,Lock
257 92LSP0304306 J AB Spring,Lock Gear
258 KMECB0018AWZZ J BE Tape Mechanism Ass’y
258- 1 92PF513-853 J BL Head Plate Block [Tape 2]
258- 2 92PF525-336 J Motor with Pulley [Tape]
258- 3 92PF567-677 J Tape Mechanism PWB Ass’y
258- 4 92PFF19N-21 J Belt,Main [Tape 2]
258- 5 92PF514-133 J AL Pinch Roller
258- 6 92PF19S-31 J Belt,FF/REW [Tape 2]
258- 7 92PFF19N-11 J Belt,Main [Tape 1]
258- 8 92PF522-061 J Clutch Ass’y Block [Tape 1]
258- 9 92PFF19S-52 J Belt,FF/REW [Tape 1]
258-10 92PF513-861 J Head Plate Block [Tape 1]
258-11 92PF522-063 J Clutch Ass’y Block [Tape 2]
259 PCOVQ3002AWZZ J AL Fan Cover
260 92LCAUT1706B J AA Label,Laser
261 92LCAUT1706A1 J AC Label,Class 3
262 LANGK0287AWFW J AC Bracket, Transformer Support
601 LX-BZ2222AXZZ J AB Screw,Special
602 XJBSD30P12000 J AA Screw,ø3×12mm
603 LX-JZ0010AFFD J AA Screw,ø3×10mm
604 XEBSD26P08000 J AA Screw,ø2.6×8mm
605 XBBSD20P04000 J AA Screw,ø2×4mm
606 XEBSD30P10000 J AA Screw,ø3×10mm
607 XEBSD30P12000 J AA Screw,ø3×12mm
608 XESSD30P10000 J AA Screw,ø3×10mm
610 XJBSD30P10000 J AA Screw,ø3×10mm
611 XJBSD30P14000 J AA Screw,ø3×14mm
613 XJSSD30P10000 J AA Screw,ø3×10mm
614 92LSC0308MBZI J AB Screw,ø3×8mm
615 92LSC0308RBZI J AB Screw,ø3×8mm
616 XHBSD40P08000 J AA Screw,ø4×8mm
ACCESSORIES/PACKING PARTS
QANTL0008AWZZ J AH AM Loop Antenna
1 QPLGA0003AWZZ J AF Adaptor,AC Plug
1 QPLGA0004AWZZ J AF Adaptor,AC Plug
SPAKA0300AWZZ J AM Packing Add.
SPAKC1145AWZZ J Packing Case
[CD-BK250W Except for
Australia/New Zealand]
SPAKC1237AWZZ J Packing Case
[CD-BK250W for Australia/New
Zealand]
SPAKC1238AWZZ J Packing Case
[CD-BK250W for Australia/New
Zealand]
SPAKC1239AWZZ J Packing Case
[CD-BK2600W Except for
Australia/New Zealand]
SPAKC1258AWZZ J Packing Case
[CD-BK270W for Australia/New
Zealand]
SPAKC1259AWZZ J Packing Case
[CD-BK270W Except for
Australia/New Zealand]
SPAKP0013AWZZ J AC Polyethylene Bag,Unit
SPAKZ0771AWZZ J AF Center Pad
SPAKZ0773AWZZ J AE Top Pad
SSAKA0007AWZZ J AB Polyethylene Bag,Accessories
TCAUA0061AWZZ J Caution Tag [For Taiwan Only]
TGANE0011AW70 J Warranty Card
[CD-BK250W for Philippines]
TGANE0011AW71 J Warranty Card
[CD-BK2600W for Philippines]
TGANE0011AW76 J Warranty Card
[CD-BK270W for Philippines]
TGANZ0028AW74 J Warranty Card
[CD-BK250W for Taiwan]
TGANZ0028AW75 J Warranty Card
[CD-BK2600W for Taiwan]
TGANZ0028AW82 J Warranty Card
[CD-BK270W for Taiwan]
TINST0096AWZZ J Operation Manual
[CD-BK250W/CD-BK2600W for
Thailand]
TINST0100AWZZ J Operation Manual
[CD-BK270W for Thailand]
TINSZ0691AWZZ J Operation Manual
[CD-BK250W/CD-BK2600W
Except for Thailand/Australia/
New Zealand]
TINSZ0692AWZZ J Operation Manual
[CD-BK250W/CD-BK2600W for
Australia/New Zealand]
TINSZ0714AWZZ J Operation Manual
[CD-BK270W Except for
Thailand/Australia/New Zealand]
TINSZ0715AWZZ J Operation Manual
[CD-BK270W for Australia/New
Zealand]
TLABB0001AWZZ J AB Label,Japan
TLABE0477AWZZ J Label,Bar Code [CD-BK250W]
TLABE0478AWZZ J Label,Bar Code [CD-BK2600W]
TLABE0518AWZZ J Label,Bar Code [CD-BK250W]
TLABE0519AWZZ J Label,Bar Code [CD-BK2600W]
TLABE0575AWZZ J Label,Bar Code [CD-BK270W]
TLABE0579AWZZ J Label,Bar Code [CD-BK270W]
TLABJ0003AWZZ J AB Label,Japan,Packing Case
TLABR1226AWZZ J Label,Bar Code [CD-BK250W]
TLABR1227AWZZ J Label,Bar Code [CD-BK2600W]
TLABZ0838AWZZ J Label,FDA
TLABZ0937AWZZ J Label,Carton
[CD-BK250W for Taiwan]
TLABZ0938AWZZ J Label,Feature [Tape 1]
[Except for Australia/New
Zealand]
TLABZ0939AWZZ J Label,Feature [Tape 2]
TLABZ0940AWZZ J Label,Carton
[CD-BK2600W for Taiwan]
TLABZ0951AWZZ J Label,Feature [Tape 1]
[For Australia/New Zealand]
TLABZ0963AWZZ J Label,Carton
[CD-BK270W for Thailand]
92LBAG760C J AA Bag,Plug Adaptor
92LFANT1746A J AD FM Antenna
92LGCARD1266E1 J AC Warranty Card
92LLABL1507B J AA Label,Packing Case,MADE IN
MALAYSIA
92LPANEL713A J AB Panel,MADE IN MALAYSIA
RRMCG0267AWSA J Remote Control
GFTAB1022AWSB J Battery Lid,Remote Control
– 6 –
