NAMES
OF
PARTS
Illustration:
CD-C250X
W
Front
panel
1.
Disc Tray
2. Disc Skip Button
3. Open/Close Button: &
4.
CD Repeat Indicator:
c
5. CD Pause Indicator: II
6.
Disc Number Indicator
7. FM Stereo Mode Indicator
8.
Extra Bass Indicator: X-BASS
9. Random Indicator
10.
CD Play Indicator:
)
11.
Record Indicator
12.
Preset Channel Indicator
13.
FM Stereo Indicator:
co
14. Function/Track Number/CD Counter/
~,.
Band/Frequency/Volume Indicator
15.
Memory Indicator
16.
Power Switch
17.
Record Start Button:
0
18.
Stand-By Indicator
19.
Remote Control Sensor
20.
Extra Bass Button: X-BASS
21.
Disc Number Select Buttons
22.
Function Selector Buttons
23.
Volume Up/Down Buttons:
A/V
24.
Tuning
Up/Down
Buttons:
A/V
25.
Reset Button
26.
Track Down/Review/Preset Down Button:
+rn+r
27.
Stop Button:
w
28.
Play/Repeat Button:
WC
29.
Track Up/Cue/Preset Up Button:
Ic+h+l
30.
Equalizer Mode Button
31.
Memory Button
32.
Headp~hones
Socket
33.
(TAPE 1) Cassette Compartment
34.
(TAPE 2) Cassette Compartment
45
6
78
9
1011
12 13 14
%
15
6171819
(2021
2223
24
25
26
272829.30
31
32
~-
33 34
-3-
