Sharp CD-C811W - System Specifications

CD-C811W/821W
– 3 –
CP-C811W
Specifications for this model are subject to change without
prior notice.
SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
CD-C811W/821W
CP-C821W
● Front speaker section
Type: 2-way type [13 cm (5-1/4") woofer
and super tweeter]
Maximum input power: 30 W
Rated input power: 15 W
Impedance: 5.4 ohms
Dimensions: Width; 180 mm (7-1/8")
Height; 300 mm (11-13/16")
Depth; 215 mm (8-7/16")
Weight: 2.0 kg (4.4 lbs.)/each
● Surround speaker section
Type: 8 cm (3-1/4") full-range speaker
Maximum input power: 10 W
Rated input power: 5 W
Impedance: 16 ohms
Dimensions: Width; 170 mm (6-3/4")
Height; 170 mm (6-3/4")
Depth; 88 mm (3-1/2")
Weight: 0.6 kg (1.2 lbs.)/each
GBOXS0028AWM1
● General (CDC821W)
Power source: AC 110/127/220/230-240 V,
50/60 Hz
Power consumption: 47 W
Dimensions: Width; 270 mm (10-5/8")
Height; 300 mm (11-13/16")
Depth; 353 mm (13-7/8")
Weight: 5.5 kg (12.1 lbs.)
● Amplifier section (CDC821W)
Output power: MPO; 60 W (30 W + 30 W)
(10 % T.H.D.)
RMS; 40 W (20 W + 20 W)
(10 % T.H.D.)
RMS; 28 W (14 W + 14 W)
(0.9 % T.H.D.)
Output terminals: Front speakers; 5.4 ohms
Surround speakers; 16 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
● Compact disc player section
Type: 3-disc multi-play compact
disc player
Signal readout: Non-contact, 3-beam semi-
conductor laser pickup
D/A converter: 1-bit D/A converter
Frequency
response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz)
● Tuner section
Frequency range: FM; 88-108 MHz
AM; 531 - 1,602 kHz
● General (CD-C811W)
Power source: AC 110/127/220/230-240 V,
50/60 Hz
Power consumption: 40 W
Dimensions: Width; 270 mm (10-5/8")
Height; 300 mm (11-13/16")
Depth; 353 mm (13-7/8")
Weight: 5.1 kg (11.2 lbs)
● Amplifier section (CD-C811W)
Output power: MPO; 33 W (16.5 W + 16.5 W)
(10 % T.H.D.)
RMS; 20 W (10 W + 10 W)
(10 % T.H.D.)
RMS; 16 W (8 W + 8 W)
(0.9 % T.H.D.)
Output terminals: Speakers; 8 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
● Front speaker section
Type:
10 cm (4") full range speaker
Maximum input power:
20 W
Rated input power:
10 W
Impedance:
8 ohms
Dimensions:
Width; 180 mm (7-1/8")
Height; 300 mm (11-13/16")
Depth; 204 mm (8-1/16")
Weight:
2.0 kg (4.4 lbs)/each
● Cassette deck section
Type: Compact cassette tape
Frequency response: 50-14,000 Hz (Normal tape)
Motor: DC motor with electronic governor × 1
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Bias and erasure
system: AC
Tape speed: 4.76 cm/sec. (1-7/8 ips.)
Wow and flutter: 0.15 % (WRMS)
Heads: TAPE-1: Playback × 1
TAPE-2: Record/playback × 1
Erase × 1
