CD-C831W
Front Speaker
1. Tweeter
2. Woofer
3. Bass Reflex Ducts
4. Speaker Wire
Surround Speaker
1. Full Range Speaker
2. Speaker Wire
CP-C831
GBOXS0025AWM1
Remote Control
1. Remote Control Transmitter LED
CD Control section
2. Disc Number Select Buttons
3. Memory Button
4. Pause Button
5. Clear Button
6. Track Down/Review Button
7. Track Up/Cue Button
8. Disc Skip Button
9. Play/Repeat Button
10. Stop Button
11. Random Button
Tuner control section
12. Preset Up/Down Buttons
Tape control section
13. (TAPE 1) Play Button
14. (TAPE 2) Record Pause Button
15. (TAPE 1/2) Stop Button
16. (TAPE 2) Play Button
17. (TAPE 2) Rewind Button
18. (TAPE 2) Fast Forward Button
Common section
19. Equalizer Mode Selector Button
20. Function Selector Buttons
21. On/Stand-by Button
22. Extra Bass Button
23. Volume Up/Down Buttons
Rear Panel
1. AC Voltage Selector
2. AC Power Input Socket
3. AM Aerial Terminal
4. Aerial Earth Terminal
5. FM 75 Ohms Aerial Socket
6. Video/Auxiliary (Audio Signal) Input Sockets
7. Span Selector Switch
8. Surround Speaker Terminals
9. Front Speaker Terminals
5
1
6
2
3
4
7
8
9
1
2
3
4
1
2
1
8
3
4
10
9
5
6
7
11
12
13 14
16 17 18
20
19
21 23
2
15
22
