PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-C831W
CNP701 QCNCWZG22AWZZ J AE Socket,22Pin
CNP801 QCNCM042EAWZZ J AB Plug,5Pin
CNP802 QCNCM035HAWZZ J AB Plug,8Pin
CNP804 92LCONE2P53253 J AB Plug,2Pin
CNP806 QCNCM705DAFZZ J AB Plug,4Pin
CNPM1 QCNCM932MAFZZ J AE Plug,12Pin
CNPM2 QCNCM030BAWZZ J AB Pin Holder
CNS1A/B QCNWN1181AWZZ J AK Connector Ass’y,5/5Pin
CNS2A/B QCNWN1182AWZZ J AH Connector Ass’y,8/8Pin
CNS3A/B QCNWN1183AWZZ J AG Connector Ass’y,6/6Pin
CNS101 QCNWN1384AWZZ J AL Connector Ass’y,3Pin
CNS102 QCNWN1385AWZZ J AG Connector Ass’y,7Pin
CNS303 QCNCM010JAWZZ J Connector Ass’y,9Pin
CNS701 QCNCWZF22AWZZ J AE Socket,22Pin
CNS804 QCNWN1389AWZZ J AC Connector Ass’y,2Pin
! F802,803 92LFUSE-T402E J AD Fuse,T4.0A L 250V
! F805 92LFUSE-T202E J AD Fuse,T2.0A L 250V
! F832 92LFUSET501E J AD Fuse,T500mA L 250V
FFC701 QCNWN1467AWZZ J AG Flat Cable,22Pin
FL701 VVKBJ685GNK-1 J AV FL Display
FW702 QCNWN1387AWZZ J AF Flat Wire,8Pin
FW801 QCNWN1388AWZZ J AD Flat Wire,5Pin
FWM1 QCNWN1274AWZZ J AC Flat Wire,2Pin
FWM2 QCNWN0338AWZZ J AD Flat Wire,2Pin
IC99 VHPGP1F32T/-1 J AP Optical Fiber Data
Link,GP1F32T
JK601 QSOCJ0213AWZZ J AE Jack,Video In
JK970 QJAKM0010AWZZ J AF Jack,Headphones
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 RMOTV0373AFZZ J AL Motor with Worm Pulley
[T/T Up/Down Loading]
M901 92LMTR1810A J AK Motor,Air Cooling Fan
MM1(204-7) RMOTV0006AWM1 J AR Motor with Pulley [Tape]
PHM1 VHPI31535CD-1 J AG Photo Interrupter
RL801 RRLYD0001SJZZ J AQ Relay
RL901 RRLYD0004AWZZ J AP Relay
RX701 VHLN63H380A-1 J AK Remote Sensor,N63H380A
SO301B QTANC0301AWZZ J AH Terminal,Antenna
! SO801 QSOCA0209AWZZ J AH Socket,AC Input
SO901 QTANA0803AWZZ J AH Terminal,Speaker
SOLM1(204-8) RPLU-0002AWZZ J AH Solenoid Ass’y [Tape]
SOLM2 RPLU-0002AWZZ J AH Solenoid Ass’y [CD]
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
SW601 QSW-S0024AWZZ J AE Switch,Slide Type
[Span Selector]
SW701 92LSWICH1401AT J AC Switch,Key Type
[ON/STAND-BY]
SW703 92LSWICH1401AT J AC Switch,Key Type [CLOCK]
SW704 92LSWICH1401AT J AC Switch,Key Type
[TIMER/SLEEP]
SW705 92LSWICH1401AT J AC Switch,Key Type [DISC 1]
SW706 92LSWICH1401AT J AC Switch,Key Type [DISC 2]
SW707 92LSWICH1401AT J AC Switch,Key Type [DISC 3]
SW708 92LSWICH1401AT J AC Switch,Key Type [DISC SKIP]
SW709 92LSWICH1401AT J AC Switch,Key Type
[OPEN/CLOSE]
SW710 92LSWICH1401AT J AC Switch,Key Type [REV]
SW711 92LSWICH1401AT J AC Switch,Key Type [REC PAUSE]
SW712 92LSWICH1401AT J AC Switch,Key Type
[MEMORY/SET]
SW713 92LSWICH1401AT J AC Switch,Key Type [STOP]
SW714 92LSWICH1401AT J AC Switch,Key Type
[TUNER/BAND]
SW715 92LSWICH1401AT J AC Switch,Key Type [VIDEO]
SW716 92LSWICH1401AT J AC Switch,Key Type [TAPE]
SW717 92LSWICH1401AT J AC Switch,Key Type [CD]
SW722 92LSWICH1401AT J AC Switch,Key Type [FF]
SW723 92LSWICH1401AT J AC Switch,Key Type [TUNING UP]
SW724 92LSWICH1401AT J AC Switch,Key Type
[TUNING DOWN]
SW725 92LSWICH1401AT J AC Switch,Key Type [PLAY]
SW726 92LSWICH1401AT J AC Switch,Key Type
[VOLUME DOWN]
SW727 92LSWICH1401AT J AC Switch,Key Type [VOLUME UP]
SW728 92LSWICH1401AT J AC Switch,Key Type
[X-BASS/DEMO]
SW729 92LSWICH1401AT J AC Switch,Key Type [EQUALIZER]
SW730 92LSWICH1401AT J AC Switch,Key Type [DIMMER]
! SW801 QSOCE0008AWZZ J AH Switch,Slide Type
[Voltage Selector]
SWM3(204-9) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
SWM4(204-10) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S]
SWM5(204-11) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
WTM801 QCNCW012EAWZZ J AC Plug,5Pin
CD MECHANISM PARTS
301 NGERH0011AWZZ J AC Gear,Middle
302 NGERH0012AWZZ J AC Gear,Drive
303 MLEVP0010AWZZ J AC Rail,Guide
304 NSFTM0002AWFW J AE Shaft,Guide
305 92LM-CUSN1524A J AC Cushion
! 306 92LHPC1MASY J BG Pickup Unit Ass’y
306- 1 ———— –– Pickup Unit
(Not Replacement Item)
306- 2 NGERR0043AFZZ J AC Gear,Rack
306- 3 MSPRC0961AFZZ J AA Spring,Rack
701 XBSSD26P06000 J AA Screw,ø2.6×6mm
702 XHBSD20P05000 J AA Screw,ø2×5mm
703 XBBSD20P03000 J AA Screw,ø2×3mm
704 LX-WZ1070AFZZ J AA Washer,ø1.5×ø3.8×0.25mm
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
CABINET PARTS
201 GCAB-1044AWSA J AM CD Player Base
202 GCAB-1052AWSA J AP Top Cabinet
203 GITAR4050AWSA J AK Back Board
204 92LMEC2744AS1 J BK Tape Mechanism Ass’y
204- 1 NBLTK0011AWZZ J AC Belt,Main,Tape 1
204- 2 NBLTK0012AWZZ J AB Belt,Main,Tape 2
204- 3 NBLTK0030AWZZ J AC Belt,Sub
204- 4 NROLY0002AWZZ J AF Pinch Roller Ass’y
204- 5 RHEDA0001AWZZ J AG Head,Erase
204- 6 92LMRPH1746A J AM Head,Record/Playback
[Tape 1/Tape 2]
204- 7(MM1) RMOTV0006AWM1 J AR Motor with Pulley [Tape]
204- 8(SOLM1) RPLU-0002AWZZ J AH Solenoid Ass’y [Tape]
204- 9(SWM3) 92LM-SW1676A J AC Switch,Leaf Type [Fool Proof]
204-10(SWM4) QSW-F9003AWZZ J AG Switch,Leaf Type [F.A.S]
204-11(SWM5) 92LM-SW1658A J AB Switch,Leaf Type [CAM]
205 LANGK0163AWFW J AB Bracket,Fan Support
206 LCHSM0082AWFW J AP Main Chassis
207 LANGF0032AWZZ J AC Support,T/T Lock Lever
208 PCUSG0022AWZZ J AB Cushion,Leg
209 PRDAR0130AWFW J AM Heat Sink,Main
210 LCHSZ0010AWZZ J AM Chassis,Loading
211 LCHSZ0011AWZZ J AG Chassis,CD Mechanism
212 PRDAR0127AWFW J AM Heat Sink,Sub
213 LHLDZ1140AWZZ J AB Guide
214 LHLDZ1141AWZZ J AB Support,Pitch
215 LHLDZ1213AWZZ J AE Holder,FL
216 MLEVP0066AWZZ J AE Lever,Shift
217 MLEVP0067AWZZ J AC Lever,Lock
218 MLEVP0068AWZZ J AB Lever,Change
219 MLEVP0070AWZZ J AB Lever,T/T Lock
221 MSPRC0020AWFJ J AB Spring,T/T Lock Lever
222 MSPRC0024AWFW J AB Spring,Solenoid
223 MSPRD0044AWFJ J AB Spring,Lock Lever
224 92LMEC3022CTS1 J AM Cassette Holder Ass’y,Tape 1
224- 1 ———— –– Cassette Holder,Tape 1
(Not Replacement Item)
224- 2 GCOVA1221AWSA J AH Cover,Cassette,Tape 1
224- 3 HDECQ0408AWSA J AD Panel,Cassette,Tape 1
225 92LMEC3022CTS2 J AM Cassette Holder Ass’y,Tape 2
225- 1 ———— –– Cassette Holder,Tape 2
(Not Replacement Item)
225- 2 GCOVA1222AWSA J AH Cover,Cassette,Tape 2
225- 3 HDECQ0409AWSA J AD Panel,Cassette,Tape 2
226 NBLTK0033AWZZ J AC Belt,Drive
227 LHLDZ1228AWZZ J AC Holder,LED,A
228 NGERH0064AWZZ J AD Gear,Cam
229 NGERH0065AWZZ J AB Gear,Turntable
230 NGERK0003AWZZ J AC Gear,Drive
231 NGERK0004AWZZ J AB Gear,Bevel
232 NGERK0005AWZZ J AB Gear,Loading
233 92LN-BAND1318A J AA Nylon Band,80mm
– 5 –
