Sharp CD-C831W User Manual

CD-C831W
– 8 –
Figure 8-1
Figure 8-2
Figure 8-3
Be Careful when installing the CD changer mechanism.
Install the CD changer mechanism on the CD player base after
the shift lever has been set in the highest position.
Figure 8-4
Figure 8-5
(G1) x1
ø3x10mm
(F1) x3
ø3x10mm
(E1) x1
ø3x10mm
(F1) x1
ø3x10mm
(E1) x2
ø3x10mm
(F4) x1
(G2) x1
Front Panel
Main PWB
Tuner PWB
(F2) x2
(F5) x1
(F3)x1
(F2) x2
(E2) x1
(G3) x1
(G3) x1
Front Panel
Display PWB
Switch PWB
Open
Cassette
Holder
Tape Mechanism
(J1)x2
ø3x10mm
(J1)x7
ø3x10mm
(J1)x3
ø3x10mm
(H1)x1
ø3x10mm
(K1)x5
ø3x10mm
(H2)x1
Headphones
PWB
(J3)x1
(J2)x2
(M1) x1
ø3 x10mm
(M1) x1
ø3 x10mm
(L1) x1
ø3 x10mm
Turntable
Disc Tray
(L2) x1
(M2) x1
(M2) x1
CD Player Unit
Washer
(N1) x1
ø3 x10mm
(N2) x2
(N2) x2
CD Player Unit
CD Servo PWB
(P1) x4
ø3 x12mm
(Q1) x1
ø2.6 x10mm
CD Changer
Mechanism
CD Mechanism
Shift Lever
CD Player Base
