CD-ES600/CD-ES66
2 – 32
BEFORE MELT IT
AFTER MELT IT ( MUST FLAT )
CHANGE COLOR
TO NATURE
ROTATE ANTI CLOCKWISE BY JIG
( BY HAND CANNOT X )
AFTER ASSY TO HOLDER
STABILIZER NEED CLEAN
WITH ALCOHOL DISC
TO UCHING SURFACE
APPLY DIABOND
stabilizer already changed
as in above picture item 3
BELOW
FIGURE 1
30
