Sharp CD-ES600 User Manual

CD-ES600/CD-ES66
3 – 3
(A1)x4
φ4x35mm
(A2)x1
Speaker Box
Front Panel
Passive Radiator
1 Passive Radiator 1. Screw ...................... (A1) x4
2. Side Pane l .............. (A2) x1
3. Screw ...................... (A3) x4
2 Woofer 1. Front Panel ............. (B1) x1
2. Screw ...................... (B2) x4
3 Tweeter 1. Screw ...................... (C1) x2
STEP
REMOVAL PROCEDURE
CP-ES600/CP-ES66
Speaker Box
(B1)x1
Screwdriver
Driver should
be pried away
from Speaker Box.
(A3)x4
φ4x16mm
(B2)x4
φ4x16mm
Passive Radiator
Woofer
Tweeter
(C1)x2
φ3x12mm
Speaker Box
