General Information
 Front speaker
1. Woofer
2. Tweeter
3. Bass Reflex Duct
4. Speaker Terminals
Note:
The speaker grilles are not removable.
 Active subwoofer
Reference page
1. Subwoofer
2. Bass Reflex Duct
3. Power Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5. Crossover Frequency Control . . . . . . . . . . . . . . . . . . . . . . 17
6. Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7. Subwoofer Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Note:
The subwoofer grilles are not removable.
1
3
4
2
1
3
2
4
5
6
7
8
