E-9
ENGLISH
CD-G14000
CD-G17000
CD-G22000
2008/April/25 CD-G14000/17000/22000
Preparation for Use
System connections
75 OHMS
FM
GND
AM
ANTENNA
RATED SPEAKER IMPEDANCE : 6 OHMS MIN.
Subwoofer
connection
(see page 14)
FM
aerial
AM loop
aerial
Front
speaker
(left)
Speaker connection
(see page 12)
Aerial connection (see page 12)
To wall socket (AC 120 V ~ 60 Hz)
To wall socket (AC 120 V ~ 60 Hz)
Make sure to unplug the AC power lead before making any connections.
Front
speaker
(right)
Active subwoofer
AC power connection (see page 15)
(CD-G14000)
To Next Page
