Sharp CD-K491W User Manual

– 5 –
CD-K491W
62 63
VIDEO OUT
MONITOR
SPAN
SELECTOR
FM/MW(kHZ)
50/9
100/10
1
234
5
67
8
10
11
13
15 16
17 18
9
12
14
44 45
46 47 48 49 50 51
52
53 54 55
56
57 58 59 60
61
■ Rear panel
44. Clock Button
45. Sleep Button
46. Reverse Mode Button
47. CD Pause Button
48. Jog Dial
49. (CD/TAPE) Stop Button
50. Record Pause Button
51. Menu Button
52. Item Button
53. Timer Button
54. Memory Button
55. Clear Button
56. (CD) Track Down/Review Button
(TAPE 2) Fast Wind Button
(TUNER) Tuning Down Button
57. (TAPE 2) Reverse Play Button
58. (CD) Play/Repeat Button
(TAPE 1) Play Button
(TAPE 2) Forward Play Button
59. (CD) Track Up/Cue Button
(TAPE) Fast Wind Button
(TUNER) Tuning Up Button
60. (TAPE) Normal Edit Button
61. (TAPE) High Edit/Beat Cancel Button
62. (TAPE 1) Cassette Compartment
63. (TAPE 2) Cassette Compartment
1. DVD 1 Digital Input Socket (Optical)
2. DVD 2 Digital Input Socket (Coaxial)
3. DVD 1/VCR 1 Video Input Socket
4. DVD 2/VCR 2 Video Input Socket
5. Video Output Socket
6. CD Digital Output Socket (Optical)
7. VCR 1/AUX 1 Input Socket
8. VCR 2/AUX 2 Input Socket
9. Span Selector Switch
10. 75 Ohm FM Aerial Socket
11. Aerial Earth Terminal
12. SW1/SW2/MW Aerial Terminal
13. AC Voltage Selector
14. AC Power Lead
15. Front Speaker Terminals
16. Centre Speaker Terminals
17. Surround Speaker Terminals
18. Sub Woofer Terminals

Sharp CD-K491W Specifications

General

Brand	Sharp
Model	CD-K491W
Category	Stereo System
Language	English
