– 61 –
CD-K491W
1 VREFOUT Output Buffered reference voltage output (VANA/2)
2 VREFIN Input Reference voltage input (Biased to VANA/2 internally)
3 MSC3 Input Capactior
4 MSC2 Input Capactior
5 MSC1 Input Capactior
6 GND — Ground
7 PSAVE Input Power save control (H: power save on, L: power save off)
8 MUTE Input Output mute control (H: mute on, L: mute off)
9 SPREAD Input Enhancement control (H: spread maximum, L: mute off)
10 AC Input Center speaker control (H: actual center, L: virtual center)
11 AR Input Rear speaker control (H: actual rear, L: virtual rear)
12 MO Input Monaural to virtual stereo control (H: on, L: off)
13 BYP Input Bypass control (H: Bypass On, L: Qsurround process On)
14 P/S Input Interface mode control (H: parallel I/O, L: serial I/O)
15 VDIG — Digital power supply
16 RROUT Output Rear right speaker signal out
17 RLOUT Output Rear left speaker signal out
18 COUT Output Center speaker signal out
19 FROUT Output Front right speaker out
20 FLOUT Output Front left speaker output
21 QXAC1 Input Capactior
22 QXAC2 Input Capactior
23 QXAC3 Input Capactior
24 QXAC4 Input Capactior
25 QXAC5 Input Capactior
26 QXBC1 Input Capactior
27 QXBC2 Input Capactior
28 QXBC3 Input Capactior
29 QXBC4 Input Capactior
30 QXBC5 Input Capactior
31 VANA — Analog power supply
32 QXCC1 Input Capactior
33 QXCC2 Input Capactior
34 QXCC3 Input Capactior
35 QXCC4 Input Capactior
36 QXDC1 Input Capactior
37 QXDC2 Input Capactior
38 QXDC3 Input Capactior
39 QXDC4 Input Capactior
40 FLIN Input Front left signal input
41 FRIN Input Front right signal input
42 CIN Input Center signal input
43* SUBIN Input Sub Woofer signal input
44 RLIN Input Rear left signal input
45 RRIN Input Rear right signal input
46 MSC4 Input Capactior
47 MSC5 Input Capactior
48 MSC6 Input Capactior
ICQ01 VHiQS7777PF-1: Q-Sound Decorder (QS7777PF)
Pin No.
FunctionTerminal Name
Input/Output
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
To Next Page
