Sharp CD-K491W

PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-K491W
RZ43~46 VRD-ST2CD102J J AA 1 kohm,1/6W
RZ47 VRD-MN2BD102J J AA 1 kohm,1/8W
RZ48,49 VRD-ST2CD102J J AA 1 kohm,1/6W
RZ50 VRD-MN2BD102J J AA 1 kohm,1/8W
RZ51 VRD-ST2CD102J J AA 1 kohm,1/6W
RZ52~54 VRD-MN2BD102J J AA 1 kohm,1/8W
RZ55,56 VRD-MN2BD104J J AA 100 kohm,1/8W
RZ57,58 VRD-MN2BD102J J AA 1 kohm,1/8W
RZ59,60 VRD-MN2BD272J J AA 2.7 kohms,1/8W
RZ61,62 VRD-MN2BD103J J AA 10 kohm,1/8W
RZ63,64 VRD-MN2BD104J J AA 100 kohm,1/8W
RZ65~68 VRD-ST2EE101J J AA 100 ohm,1/4W
RZ69~74 VRD-MN2BD103J J AA 10 kohm,1/8W
RZ75 VRD-ST2CD100J J AA 10 ohm,1/6W
RZ76~78 VRD-ST2CD102J J AA 1 kohm,1/6W
RZ79~84 VRD-MN2BD103J J AA 10 kohm,1/8W
RZ85,86 VRD-ST2EE102J J AA 1 kohm,1/4W
RZ87~89 VRD-MN2BD474J J AA 470 kohms,1/8W
RZ90,91 VRD-MN2BD223J J AA 22 kohms,1/8W
RZ93,94 VRD-ST2CD102J J AA 1 kohm,1/6W
RZ95 VRD-ST2CD221J J AA 220 ohms,1/6W
OTHER CIRCUITRY PARTS
BI99/CNS99 QCNWN1238AWZZ J AH Connector Ass’y,3/3Pin
BI601/CNSU02 QCNWN1270AWZZ J AH Connector Ass’y,9/9Pin
BI901/CNS901 QCNWN1225AWZZ J AL Connector Ass’y,11/11Pin
BI902/CNS902 QCNWN1226AWZZ J AF Connector Ass’y,4/4Pin
BI903/CNS903 QCNWN1227AWZZ J AK Connector Ass’y,7/7Pin
BI904/CNS904 QCNWN1229AWZZ J AK Connector Ass’y,7/7Pin
BIA11/CNSA11 QCNWN1237AWZZ J AG Connector Ass’y,2/2Pin
BIF11/CNSF11 QCNWN1233AWZZ J AF Connector Ass’y,3/3Pin
BIF12/CNSF12 QCNWN1234AWZZ J AL Connector Ass’y,14/14Pin
BIF13/CNSF13 QCNWN1239AWZZ J AH Connector Ass’y,11/11Pin
BIM5/CNS10/CNS5 QCNWN1184AWZZ J AL Connector Ass’y,6/10/2Pin
CFWA01 QCNCWZG10AWZZ J AC Socket,10Pin
CFWA02 QCNCWZG20AWZZ J AC Socket,20Pin
CFWP01 QCNCWZG16AWZZ J AD Socket,16Pin
CFWP02 QCNCWZG13AWZZ J AD Socket,13Pin
CFWU01 QCNCWZG10AWZZ J AC Socket,10Pin
CFWU02 QCNCWZG20AWZZ J AC Socket,20Pin
CFWV11 QCNCWZG16AWZZ J AD Socket,16Pin
CFWX11 QCNCWZG13AWZZ J AD Socket,13Pin
CNP1 92LCONE5P53253 J AB Plug,5Pin
CNP2 QCNCM705HAFZZ J AB Plug,8Pin
CNP3 92LCONE6P53253 J AC Plug,6Pin
CNP3A 92LCONE6P53254 J AC Plug,6Pin
CNP10 QCNCM705KAFZZ J AC Plug,11Pin
CNP11 QCNCM704CAFZZ J AB Plug,3Pin
CNP12 QCNCM704PAFZZ J AC Plug,14Pin
CNP303 QCNCM705LAFZZ J AC Plug,11Pin
CNPF01 QCNCWZS10AWZZ J AK Socket,10Pin
CNPK01 QCNCM705CAFZZ J AA Plug,3Pin
CNPK02 QCNCM705GAFZZ J AB Plug,7Pin
CNPP01 QCNCM698LAFZZ J AB Plug,11Pin
CNPP02 QCNCM705DAFZZ J AB Plug,4Pin
CNPR11 QCNCM704CAFZZ J AB Plug,3Pin
CNPR12 QCNCM704BAFZZ J AA Plug,2Pin
CNPU02 QCNCM698JAFZZ J AC Plug,9Pin
CNPV11 92LCONPB2BPHK J AB Plug,2Pin
CNPV12 QCNCM698GAFZZ J AB Plug,7Pin
CNPX12 QCNCM698GAFZZ J AB Plug,7Pin
CNS1A/B QCNWN1181AWZZ J AK Connector Ass’y,5/5Pin
CNS2A/B QCNWN1182AWZZ J AH Connector Ass’y,8/8Pin
CNS3A/B QCNWN1183AWZZ J AG Connector Ass’y,6/6Pin
CNSD01 QCNCMZS10AWZZ J AK Plug,10Pin
CNSK1 QCNWN1231AWZZ J AG Connector Ass’y,3Pin
CNSK2 QCNWN1232AWZZ J AN Connector Ass’y,7Pin
CNSV11 QCNWN1228AWZZ J AD Connector Ass’y,2Pin
! F990 92LFUSE-T502-E J AD Fuse,T5.0A L 250V
! F991 92LFUSE-T252-E J AD Fuse,T2.5A L 250V
! F992 92LFUSE-T252-E J AD Fuse,T2.5A L 250V
! F995,996 92LFUSET802E J AD Fuse,T8A L 250V
! F997 92LFUSE-T252-E J AD Fuse,T2.5A L 250V
! F998 92LFUSE-T162-E J AD Fuse,T1.6A L 250V
! F999 92LFUSE-T501-E J AD Fuse,T500mA L 250V
FE301 RTUNS0007AWZZ J AT FM Front End
FLD1 VVKBJ613GK/-1 J BD FL Display
FW901 QCNWN1301AWZZ J AC Plug,3Pin
FWA01 QCNWN1222AWZZ J AE Flat Cable,10Pin
FWA02 QCNWN1223AWZZ J AF Flat Cable,20Pin
FWD01 QCNWN0711AWZZ J AG Flat Wire,6Pin
FWD02 QCNWN1282AWZZ J AF Flat Wire,3Pin
FWM1 QCNWN1230AWZZ J AF Flat Wire,13Pin
FWM2 QCNWN0942AWZZ J AC Flat Wire,4Pin
FWP01 QCNWN1218AWZZ J AF Flat Cable,16Pin
FWP02 QCNWN1220AWZZ J AF Flat Cable,13Pin
FWV91 QCNWN1281AWZZ J AG Flat Wire,5Pin
ICA14 VHPGP1F38R/-1 J AM Terminal,Digital Input,GP1F38R
ICR11 VHPGP1F38T/-1 J AL Terminal Digital Output/LED,
GP1F38T
J601,602 92LJACK-1249A J AE Jack,Mic1/2
JA11 QJAKZ0011AWZZ J AE Jack,Digital 2 Coaxial
JH51 QSOCJ0302AWZZ J AE Jack,Video In/Out
JR11,12 QSOCJ0205AWZZ J AG Jack,VIDEO/AUX 1/2
JV91 92LJACKH1759A J AF Jack,Headphones
M1 92LMTR1858CASY J AS Motor with Chassis [Spindle]
M2 92LMTR1854BASY J AP Motor with Gear [Sled]
M3 RMOTV0373AFZZ J AL Motor with Worm Pulley
[T/T Up/Down Loading]
M901 92LMTR1810A J AK Motor,Air Cooling Fan
MM1(250-1) 92LMTR2512AASY J AT Motor with Pulley [Tape]
RLYV11 RRLYD0008AWZZ J AN Relay
RLYX11 RRLYD0008AWZZ J AN Relay
RLYY11 RRLYD0008AWZZ J AN Relay
RLYY51 RRLYD0008AWZZ J AN Relay
RXD01 VHLN64H380A-1 J AK Remote Sensor,N64H380A
SO301 QTANC0301AWZZ J AH Terminal,Antenna
SOLM1 92LM-SOL1676A J AK Solenoid
SOLM2 ———— — Solenoid Ass’y
SW1 QSW-P0004AWZZ J AE Switch,Push Type [Open/Close]
SW2 QSW-F0001AWZZ J AD Switch,Leaf/Skeleton Type
[Mecha Up]
SW3 QSW-P0005AWZZ J AD Switch,Push Type [Disc Number]
SW4 QSW-F9001AW01 J AD Switch,Leaf Type [Pickup In]
! SW991 QSOCE0008AWZZ J AH Switch,Slide Type
[Voltage Selector]
SWD01 QSW-Z0003AWZZ J AH Switch,Rotary Type
[Volume Jog]
SWD02 QSW-Z0003AWZZ J AH Switch,Rotary Type [Jog]
SWD03 92LSWICHT1663T J AC Switch,Key Type [X-BASS]
SWD04 92LSWICHT1663T J AC Switch,Key Type [PRE EQ.]
SWD05 92LSWICHT1663T J AC Switch,Key Type [MENU]
SWD06 92LSWICHT1663T J AC Switch,Key Type [ITEM]
SWD12 92LSWICHT1663T J AC Switch,Key Type
[TUNING UP/CUE]
SWD13 92LSWICHT1663T J AC Switch,Key Type [STOP]
SWD14 92LSWICHT1663T J AC Switch,Key Type
[NORMAL EDIT]
SWD15 92LSWICHT1663T J AC Switch,Key Type [HIGH EDIT]
SWD16 92LSWICHT1663T J AC Switch,Key Type [REC/PAUSE]
SWD17 92LSWICHT1663T J AC Switch,Key Type [F-PLAY]
SWD23 92LSWICHT1663T J AC Switch,Key Type [QSOUND]
SWD26 92LSWICHT1663T J AC Switch,Key Type [VIRTUAL]
SWD27 92LSWICHT1663T J AC Switch,Key Type [PHANTOM]
SWD28 92LSWICHT1663T J AC Switch,Key Type [NORMAL]
SWD29 92LSWICHT1663T J AC Switch,Key Type [BYPASS]
SWD30 92LSWICHT1663T J AC Switch,Key Type
[TUNING DOWN/REWIND]
SWD31 92LSWICHT1663T J AC Switch,Key Type [CD PAUSE]
SWD32 92LSWICHT1663T J AC Switch,Key Type
[REVERSE MODE]
SWD33 92LSWICHT1663T J AC Switch,Key Type [R-PLAY]
SWD34 92LSWICHT1663T J AC Switch,Key Type [CLOCK]
SWD35 92LSWICHT1663T J AC Switch,Key Type [MEMORY]
SWD36 92LSWICHT1663T J AC Switch,Key Type [TIMER]
SWD37 92LSWICHT1663T J AC Switch,Key Type [SLEEP]
SWD38 92LSWICHT1663T J AC Switch,Key Type [CLEAR]
SWD39 92LSWICHT1663T J AC Switch,Key Type [DVD/VIDEO 1]
SWD40 92LSWICHT1663T J AC Switch,Key Type [DVD/VIDEO 2]
SWD41 92LSWICHT1663T J AC Switch,Key Type [TAPE 1/2]
SWD42 92LSWICHT1663T J AC Switch,Key Type
[TUNER/BAND]
SWD43 92LSWICHT1663T J AC Switch,Key Type [CD]
SWD48 92LSWICHT1663T J AC Switch,Key Type
[POWER/STAND-BY]
SWD49 92LSWICHT1663T J AC Switch,Key Type [KARAOKE]
SWD50 92LSWICHT1663T J AC Switch,Key Type [DISC 1]
SWD51 92LSWICHT1663T J AC Switch,Key Type [DISC 2]
SWD52 92LSWICHT1663T J AC Switch,Key Type [DISC 3]
SWD53 92LSWICHT1663T J AC Switch,Key Type [DISC SKIP]
SWD54 92LSWICHT1663T J AC Switch,Key Type
[OPEN/CLOSE]
SWF02 QSW-S0024AWZZ J AE Switch,Slide Type
[Span Selector]
– 9 –
