CD-MD3000H/CD-MD3000W
– 2 –
LED731 VHPHLMP1700-1 J AC LED,Red,HLMP1700
LED735 VHPLNG995PF-1 J AT LED,Blue,LNG995PF
LED737,738 VHPLNG995PF-1 J AT LED,Blue,LNG995PF
LED754~759 VHPK5052UL/-1 J AD LED,Red,K5052UL
LED770 VHPL934MBC5-1 J AL LED,White,L934MBC5
LED772~775 VHPK5052UL/-1 J AD LED,Red,K5052UL
LED786 VHPK5052UL/-1 J AD LED,Red,K5052UL
LED801 VHPK5052UL/-1 J AD LED,Red,K5052UL
FILTERS
BF301 RFILR0008AWZZ J AE Band Pass Filter
[CD-MD3000W Only]
CF301 RFILF0072AFZZ J AG FM IF [CD-MD3000H Only]
CF302 RFILF0072AFZZ J AG FM IF [CD-MD3000H]
CF302 RFILF0124AFZZ J AD FM IF,10.7 MHz [CD-MD3000W]
CF351 RFILF0003AWZZ J AK FM IF
CF352 RFILA0009AWZZ J AE AM IF
FL1501~1503 RFILN0001AWZZ J AD EMI Filter
L354 RFILL0001AWZZ J AE Low Pass Filter
[CD-MD3000H Only]
TRANSFORMERS
T302 RCILA0062AWZZ J AC AM Antenna
T306 RCILB0066AWZZ J AD AM Oscillation
T311 RCILB0065AWZZ J AC FM Oscillation
[CD-MD3000W Only]
T312 RCILI0017AWZZ J AB FM IF [CD-MD3000W Only]
T351 RCILI0019AWZZ J AD AM IF
1 T801 RTRNP0325AWZZ J BG Power [CD-MD3000H]
1 T801 RTRNP0347AWZZ J Power [CD-MD3000W]
1 T802 RTRNP0313AWZZ J AN Power [CD-MD3000H]
1 T802 RTRNP0346AWZZ J Power [CD-MD3000W]
COILS
L1,2 VP-DHR82M0000 J AB 0.82 µH,Playback PLL
L7 VP-DHR82M0000 J AB 0.82 µH,Playback PLL
L104 VP-MK331K0000 J AB 330 µH,Choke
L201~204 RCILZ0137AFZZ J AA 0.29 µH
L312 RCILR0056AWZZ J AB FM RF [CD-MD3000W Only]
L341 RBLN-0001AWZZ J AD Balun [CD-MD3000H Only]
L342 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L351,352 VP-DH101K0000 J AB 100 µH,Choke
L353 VP-DH102K0000 J AB 1 mH,Choke
L501,502 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L701,702 VP-XH2R2K0000 J AB 2.2 µH,Choke
L705 VP-XH2R2K0000 J AB 2.2 µH,Choke
1 L802 RCILZ0021AWZZ J AF Line Filter
L901 VP-DH101K0000 J AB 100 µH,Choke
L910 VP-YF470K0000 J AB 47 µH,Choke
L911,912 VP-DH2R2K0000 J AB 2.2 µH,Peaking
L1100 VPBNNR47K0000 J AC 0.47 µH
L1101 VPBNN100K0000 J AC 10 µH
L1200 VPBNN4R7K0000 J AC 4.7 µH
L1201,1202 VPBNNR47K0000 J AC 0.47 µH
L1300 RCILC0358AFZZ J AC 4.7 µH,Choke
L1501 RCILZ0016AWZZ J AD 1 µH
L1502 VPBNN4R7K0000 J AC 4.7 µH
L1551,1552 VPBNNR47K0000 J AC 0.47 µH
L1554 VPBNNR47K0000 J AC 0.47 µH
L1600 RCILZ0016AWZZ J AD 1 µH
L1701,1702 VPBNN100K0000 J AC 10 µH
LT21,22 VP-XH2R2K0000 J AB 2.2 µH,Choke
[CD-MD3000H Only]
R1512 RCILZ2134SCZZ J Impeder,1 kohm at 100 MHz
R1524 RCILZ2134SCZZ J Impeder,1 kohm at 100 MHz
R1528 RCILZ2134SCZZ J Impeder,1 kohm at 100 MHz
R1540 RCILZ2134SCZZ J Impeder,1 kohm at 100 MHz
VARIABLE RESISTOR
VR351 RVR-M0026AWZZ J AC 10 kohm (B),Semi-VR
[FM Mute Level]
VARIABLE CAPACITORS
VD301 VHCSVC348S/-1 J AK Variable Capacitance,SVC348S
VD302,303 VHCSVC211C/-1 J AG Variable Capacitance,SVC211C
[CD-MD3000W Only]
VIBRATORS
X1 RCRSP0005AWZZ J AF Crystal,16.934 MHz
X351 92LCRSTL1425A J AF Crystal,456 kHz
X352 RCRSP0002AWZZ J AH Crystal,4.5 MHz
X901 RCRM-0038AFZZ J AD Ceramic,600 kHz
X902 RCRSP0011AWZZ J AC Crystal,32.768 kHz
XL1201 RCRSC0001AWZZ J AL Crystal,33.8688 MHz
XT21 RCRSP0010AWZZ J AH Crystal,4.332 MHz
[CD-MD3000H Only]
CAPACITORS
C1 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C2,3 VCTYMN1EF223Z J AA 0.022 µF,25V
C4 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C5,6 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C7 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C8 VCTYMN1EF223Z J AA 0.022 µF,25V
C10 VCTYMN1EF223Z J AA 0.022 µF,25V
C11 VCCSMN1HL150J J AA 15 pF,50V
C12 VCCSMN1HL220J J AA 22 pF,50V
C13,14 VCTYMN1EF223Z J AA 0.022 µF,25V
C15~17 VCKYPA1HF473Z J AB 0.047 µF,50V
C18 VCQYKA1HM333J J AB 0.033 µF,50V,Mylar
C19 VCKYPA1HF473Z J AB 0.047 µF,50V
C20 VCCSMN1HL470J J AA 47 pF,50V
C21 VCKYMN1HB102K J AA 0.001 µF,50V
C22 VCQYKA1HM333J J AB 0.033 µF,50V,Mylar
C23 VCTYMN1CY103K J AA 0.01 µF,16V
C24 VCTYMN1CX272K J AA 0.0027 µF,16V
C25 VCTYMN1CY103K J AA 0.01 µF,16V
C26 VCTYMN0JY153M J AA 0.015 µF,6.3V
C27 VCTYMN1CX472K J AA 0.0047 µF,16V
C28,29 VCTYMN1EF223Z J AA 0.022 µF,25V
C30 VCEAZA1AW476M J AB 47 µF,10V,Electrolytic
C31 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
C32,33 VCTYMN1EF223Z J AA 0.022 µF,25V
C34 VCCSMN1HL220J J AA 22 pF,50V
C36 VCCSMN1HL270J J AA 27 pF,50V
C37 VCTYMN1EF223Z J AA 0.022 µF,25V
C38 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C39 VCCSMN1HL3R9C J AA 3.9 pF,50V
C40,41 VCQYKA1HM104K J AB 0.1 µF,50V,Mylar
C42 VCTYMN1CX682K J AA 0.0068 µF,16V
C43 VCTYMN1EF223Z J AA 0.022 µF,25V
C44 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
C45 VCEAZA1AW477M J AC 470 µF,10V,Electrolytic
C46 VCTYMN1EF223Z J AA 0.022 µF,25V
C47,48 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C49,50 VCTYPA1HF104Z J AB 0.1 µF,50V
C51 VCEAZA1AW107M J AB 100 µF,10V,Electrolytic
C58~60 VCKYMN1HB101K J AA 100 pF,50V
C64,65 VCKYBT1HB102K J AA 0.001 µF,50V
C67 VCKYPA1HB102K J AA 0.001 µF,50V
C68 VCTYPA1HF223Z J 0.022 µF,50V
C91,92 VCKYMN1HB471J J AB 470 pF,50V
C93~99 VCKYMN1HB101K J AA 100 pF,50V
C101,102 VCKYPA1HB181K J AA 180 pF,50V
C103 VCEAZA1CW106M J AC 10 µF,16V,Electrolytic
C104,105 VCKYPA1HB561K J AA 560 pF,50V
C106,107 VCTYPA1EX333K J AA 0.033 µF,25V
C108,109 VCCSPA1HL331J J AA 330 pF,50V
C110,111 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C112,113 VCKYPA1HB561K J AA 560 pF,50V
C116 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C118 VCKYPA1HF223Z J AB 0.022 µF,50V
C119,120 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C121,122 VCKYPA1HB271K J AA 270 pF,50V
C123,124 VCTYPA1EX223K J AA 0.022 µF,25V
C125,126 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C127 VCKYPA1HB332K J AA 0.0033 µF,50V
C129,130 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C131 VCEAZA1HW226M J AB 22 µF,50V,Electrolytic
C132 VCEAZA1CW227M J AC 220 µF,16V,Electrolytic
C133 VCQYKA1HM393K J AB 0.039 µF,50V,Mylar
C134 VCEAZA1EW476M J AB 47 µF,25V,Electrolytic
C135 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C137 VCQPKA2AA822J J AA 0.0082 µF,100V,Polypropylene
C138 VCKYPA1HB332K J AA 0.0033 µF,50V
C140,141 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
