NAMES OF PARTS
CD-MD3000H/CD-MD3000W
1
2
3
4
5
6
7
8
11
9
10
■ Front panel
01.
Cassette Compartment
02.
Volume Up/Demo Button
03.
Volume Down Button
04.
Timer Set Indicator
05.
On/Stand-by Button
06.
CD Direct Play Buttons (with Indicator)/
CD Eject Buttons
07.
Disc Trays
08.
Headphone Socket
09.
MD Eject Button
10.
MD Compartment
11.
Control Panel Open/Close Button
Illustration: CD-MD3000H
■ Control panel
12.
CD/MD Play Mode Select Button
13.
Equalizer Mode Select Button
14.
Extra Bass Button
15.
Name/Toc Edit Button
16.
Delete Button
17.
Menu Button
18.
Display/Character Button
19.
Jog Dial
20.
Enter Button
21.
Tuner (Band) Button
22.
MD Track Edit Button
23.
CD Button
24.
MD Button
25.
CD MD One Touch Edit Button
26.
MD Auto Mark Select Button
27.
CD/MD Fast Reverse, Tape Fast Wind or
Tuning Down Button (with Indicator)
28.
Stop Button (with Indicator)
29.
Tape Reverse Play Button (with Indicator)
30.
Tape Button
31.
Auxiliary Button
32.
MD Record Button
33.
MD Record Mode Button
34.
MD Record Speed Select Button
35.
Tape Record Pause Button
36.
CD/MD Fast Forward, Tape Fast Wind or
Tuning Up Button (with Indicator)
37.
CD/MD Play or Pause, Tape Forward Play Button
(with Indicator)
30
31
32
33
34
35
36
37
21
22
23
24
25
26
27
28
29
12
13
14
17
15
16
18
19
20
