CD-MD3000H/CD-MD3000W
– 46 –
SW763 CD ON—OFF
SW764 MD ON—OFF
SW767 TRACK EDIT ON—OFF
SW772 EQUALIZER MODE ON—OFF
SW773 X-BASS ON—OFF
SW774 DISPLAY/CHARACTER ON—OFF
SW775 MENU ON—OFF
SW776 NAME TOC EDIT ON—OFF
SW777 DELETE ON—OFF
SW778 ENTER ON—OFF
SW780 MD EJECT ON—OFF
SW781 CD/MD ON—OFF
SW782 MD RECORD ON—OFF
SW783 PLAY MODE ON—OFF
SW901 SPAN SELECTOR 9 kHz/50 kHz
(CD-MD3000W Only)
SW1930 WRITE PRO ON—OFF
SW1931 DISC MEDIA ON—OFF
SW1932 LOADING ON—OFF
SW1933 RECORD ON—OFF
SW1934 PLAY ON—OFF
SW1936 LEAD IN ON—OFF
SWB101 DISC DETECT 1 ON—OFF
SWB102 DISC DETECT 2 ON—OFF
SWB103 DISC DETECT 3 ON—OFF
SWB104 MODE 1 ON—OFF
SWB105 MODE 2 ON—OFF
SWB106 MODE 3 ON—OFF
SWB107 MODE 4 ON—OFF
SWB108 MODE 5 ON—OFF
SWB109 TRAY 1 ON—OFF
SWB110 TRAY 2 ON—OFF
• The indicated voltage in each section is the one measured
by Digital Multimeter between such a section and the chas-
sis with no signal given.
1. In the tuner section,
( ) indicates AM
< > indicates FM stereo
2. In the main section, a tape is being played back.
3. In the deck section, a tape is being played back.
( ) indicates the record state.
4. In the power section, a tape is being played back.
5. In the CD section, the CD is stopped.
• Parts marked with “ ” ( ) are important for
maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and
performance of the set.
NOTES ON SCHEMATIC DIAGRAM
• Resistor:
To differentiate the units of resistors, such symbol as K and
M are used: the symbol K means 1000 ohm and the symbol
M means 1000 kohm and the resistor without any symbol is
ohm-type resistor. Besides, the one with “Fusible” is a fuse
type.
• Capacitor:
To indicate the unit of capacitor, a symbol P is used: this
symbol P means pico-farad and the unit of the capacitor
without such a symbol is microfarad. As to electrolytic
capacitor, the expression “capacitance/withstand voltage” is
used.
(CH), (TH), (RH), (UJ): Temperature compensation
(ML): Mylar type
(P.P.): Polypropylene type
• Schematic diagram and Wiring Side of P.W.Board for this
model are subject to change for improvement without prior
notice.
NSW1 PICKUP IN ON—OFF
SO801 VOLTAGE SELECTOR 230-240V
(CD-MD3000W Only)
SW701 POWER ON—OFF
SW705 OPEN/CLOSE ON—OFF
SW710 PANEL OPEN/CLOSE ON—OFF
SW711 VOLUME DOWN ON—OFF
SW712 VOLUME UP ON—OFF
SW720 CD 1 EJECT ON—OFF
SW721 CD 2 EJECT ON—OFF
SW722 CD 3 EJECT ON—OFF
SW723 CD 4 EJECT ON—OFF
SW724 CD 5 EJECT ON—OFF
SW725 CD 6 EJECT ON—OFF
SW730 CD 1 PLAY ON—OFF
SW731 CD 2 PLAY ON—OFF
SW732 CD 3 PLAY ON—OFF
SW733 CD 4 PLAY ON—OFF
SW734 CD 5 PLAY ON—OFF
SW735 CD 6 PLAY ON—OFF
SW750 HIGH/NORMAL ON—OFF
SW751 RECORD/MODE ON—OFF
SW752 AUTO MARKER ON—OFF
SW753 FAST REVERSE ON—OFF
SW754 FAST FORWARD ON—OFF
SW755 TAPE RECORD ON—OFF
SW756 PLAY/PAUSE ON—OFF
SW757 STOP ON—OFF
SW758 PLAY ON—OFF
SW760 AUX ON—OFF
SW761 TAPE ON—OFF
SW762 TUNER ON—OFF
REF. NO
DESCRIPTION
POSITION
POSITIONREF. NO DESCRIPTION
