NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
CD-MD3000H/CD-MD3000W
– 8 –
CNP207 92LCONE4P53254 J AC Plug,4Pin
CNP301 92LCONE2P5268 J AB Plug,2Pin [CD-MD3000H Only]
CNP303 92LCONE3P5268 J AC Plug,3Pin [CD-MD3000W Only]
CNP701 QCNCWZG05AWZZ J AB Socket,5Pin
CNP721 92LCONE6P53254 J AC Plug,6Pin
CNP775 92LCONE2P53253 J AB Plug,2Pin
CNP801 QCNCM049BAWZZ J AC Plug,2Pin [CD-MD3000H]
CNP801 QCNCM049EAWZZ J AD Plug,5Pin [CD-MD3000W]
CNP802 QCNCM051EAWZZ J AD Plug,5Pin
CNP803 QCNCM035EAWZZ J Plug,5Pin
CNP805 92LCONE8P5268 J Plug,8Pin
CNP806 QCNCM010QAWZZ J AD Plug,15Pin
CNP807 QCNCM010NAWZZ J AC Plug,13Pin
CNP901 QCNCWZF33AWZZ J AF Socket,33Pin
CNP920 QCNCWYW28AWZZJ AK Socket,28Pin
CNP921 92LCONPB4BPHK J AC Plug,4Pin
CNP925 92LCONE4P53253 J AB Plug,4Pin
CNP931 92LCONPB11BPHK J AC Plug,11Pin
CNP933 92LCONE5P53253 J AB Plug,5Pin
CNP934 92LCONE7P53253 J AC Plug,7Pin
CNP935 92LCONPB6BPHK J AB Plug,6Pin
CNP970 QCNCWZG12AWZZ J AC Socket,12Pin
CNP975 92LCONPB2BPHK J AB Plug,2Pin
CNS4 QCNWN1692AWZZ J AD Connector Ass’y,4Pin
CNS5A/B QCNWN1690AWZZ J AG Connector Ass’y,8/8Pin
CNS6A/B QCNWN1668AWZZ J AF Connector Ass’y,6/6Pin
CNS7A/B QCNWN1689AWZZ J AF Connector Ass’y,7/7Pin
CNS200 QCNWN1659AWZZ J AC Connector Ass’y,2Pin
CNS205 QCNWN1861AWZZ J Connector Ass’y,2Pin
[CD-MD3000W Only]
COR801 RCORF0015AWZZ J AB Core
CORE1 RCORF0015AWZZ J AB Core
CORE2 RCORF0015AWZZ J AB Core
CW1501 QCNWN6770AFM1 J AR Flat Cable,28Pin
CW1502A/B QCNWN1515AWZZ J AK Connector Ass’y,4/4Pin
CW1931 QCNWN1512AWZZ J AC Flat Cable,5Pin
CW1932 QCNWN1513AWZZ J AC Flat Cable,6Pin
1 F801 92LFUSET202E J AC Fuse,T2A L 250V
1 F802 92LFUSET252E J AD Fuse,T2.5A L 250V
1 F803,804 92LFUSET502E J AC Fuse,T5A L 250V
1 F805,806 92LFUSET402E J AD Fuse,T3.15A L 250V
1 F807 92LFUSET312E J AD Fuse,T3.15A L 250V
[CD-MD3000H Only]
1 F808 92LFUSET202E J AC Fuse,T2A L 250V
FE301 RTUNS0016AWZZ J AX FM Front End
[CD-MD3000H Only]
FFC901 QCNWN1672AWZZ J AF Flat Cable,33Pin
FFC970 QCNWN1686AWZZ J AE Flat Cable,12Pin
FW2 QCNWN1691AWZZ J AD Flat Wire,8Pin
FW3 QCNWN1693AWZZ J AC Flat Wire,4Pin
JK501 92LJACKL1776A J AF Jack,AUX
JK701 QJAKM0010AWZZ J AF Jack,Headphones
JOG701 QSW-Z0011AWZZ J AG Switch,Push Type [Jog Dial]
LCD720 RUNTZ0020AWZZ J BC LCD Display
M901 RMOTV0025AWZZ J AV MD Spindle Motor Ass’y
M902 92LMTR3167BASY J AP MD Sled Motor Ass’y
M903 92LMTR3167AASY J AN MD Loading Motor Ass’y
MO200 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
MO201 RMOTV0027AWZZ J AM Motor,Air Cooling Fan
[CD-MD3000W Only]
MO700 RMOTV0027AWZZ J AM Motor,Control Panel
MOB1 92LMTR3435DASY J AM Main Cam Motor Ass’y
MOB2 92LMTR3435DASY J AM Tray Motor Ass’y
NM1 92LMTR2996CASY J AS Motor with Chassis [Spindle]
NM2 92LMTR1854BASY J AP Motor with Gear [Sled]
NSW1 QSW-F9001AW01 J AD Switch,Push Type [Pickup In]
RX701 VHLN64H380A-1 J AK Remote Sensor,N64H380A
1 RY201,202 RRLYD0004AWZZ J AP Relay
1 RY801 RRLYD0001SJZZ J AQ Relay
SO201 QTANA0806AWZZ J AG Terminal,Speaker
SO301 QTANC0103AWZZ J AD Antenna Terminal
[CD-MD3000H Only]
1 SO801 QSOCE0008AWZZ J AH Switch,Slide Type [Voltage
Selector] [CD-MD3000W Only]
SW701 92LSWICH1401AT J AC Switch,Key Type [Power]
SW705 QSW-B0002AWZZ J AF Switch,Lever Type [Open/Close]
SW710 92LSWICH1401AT J AC Switch,Key Type
[Panel Open/Close]
SW711 92LSWICH1401AT J AC Switch,Key Type [Volume Down]
SW712 92LSWICH1401AT J AC Switch,Key Type [Volume Up]
SW720 92LSWICH1401AT J AC Switch,Key Type [CD1 Eject]
SW721 92LSWICH1401AT J AC Switch,Key Type [CD2 Eject]
SW722 92LSWICH1401AT J AC Switch,Key Type [CD3 Eject]
SW723 92LSWICH1401AT J AC Switch,Key Type [CD4 Eject]
SW724 92LSWICH1401AT J AC Switch,Key Type [CD5 Eject]
SW725 92LSWICH1401AT J AC Switch,Key Type [CD6 Eject]
SW730 92LSWICH1401AT J AC Switch,Key Type [CD1 Play]
SW731 92LSWICH1401AT J AC Switch,Key Type [CD2 Play]
SW732 92LSWICH1401AT J AC Switch,Key Type [CD3 Play]
SW733 92LSWICH1401AT J AC Switch,Key Type [CD4 Play]
SW734 92LSWICH1401AT J AC Switch,Key Type [CD5 Play]
SW735 92LSWICH1401AT J AC Switch,Key Type [CD6 Play]
SW750 92LSWICH1401AT J AC Switch,Key Type [High/Normal]
SW751 92LSWICH1401AT J AC Switch,Key Type [Record/Mode]
SW752 92LSWICH1401AT J AC Switch,Key Type [Auto Marker]
SW753 92LSWICH1401AT J AC Switch,Key Type [Fast Reverse]
SW754 92LSWICH1401AT J AC Switch,Key Type [Fast Forward]
SW755 92LSWICH1401AT J AC Switch,Key Type [Tape Record]
SW756 92LSWICH1401AT J AC Switch,Key Type [Play/Pause]
SW757 92LSWICH1401AT J AC Switch,Key Type [Stop]
SW758 92LSWICH1401AT J AC Switch,Key Type [Play]
SW760 92LSWICH1401AT J AC Switch,Key Type [AUX]
SW761 92LSWICH1401AT J AC Switch,Key Type [Tape]
SW762 92LSWICH1401AT J AC Switch,Key Type [Tuner]
SW763 92LSWICH1401AT J AC Switch,Key Type [CD]
SW764 92LSWICH1401AT J AC Switch,Key Type [MD]
SW767 92LSWICH1401AT J AC Switch,Key Type [Track Edit]
SW772 92LSWICH1401AT J AC Switch,Key Type
[Equalizer Mode]
SW773 92LSWICH1401AT J AC Switch,Key Type [X-BASS]
SW774 92LSWICH1401AT J AC Switch,Key Type
[Display Character]
SW775 92LSWICH1401AT J AC Switch,Key Type [Menu]
SW776 92LSWICH1401AT J AC Switch,Key Type
[Name TOC Edit]
SW777 92LSWICH1401AT J AC Switch,Key Type [Delete]
SW778 92LSWICH1401AT J AC Switch,Key Type [Enter]
SW780 92LSWICH1401AT J AC Switch,Key Type [MD Eject]
SW781 92LSWICH1401AT J AC Switch,Key Type [CD/MD]
SW782 92LSWICH1401AT J AC Switch,Key Type MD [Record]
SW783 92LSWICH1401AT J AC Switch,Key Type [Play Mode]
SW901 QSW-S0024AWZZ J AE Switch,Slide Type
[Span Selector]
[CD-MD3000W Only]
SW1930 QSW-P0011AWZZ J AD Switch,Push Type [Write Pro]
SW1931 QSW-P0012AWZZ J AD Switch,Push Type [Disc Media]
SW1932 QSW-M0007AWZZ J AD Switch,Push Type [Loading]
SW1933 QSW-M0007AWZZ J AD Switch,Push Type [Record]
SW1934 QSW-M0007AWZZ J AD Switch,Push Type [Play]
SW1936 QSW-M0157AFZZ J AD Switch,Slide Type [Lead In]
SWB101 QSW-P9005AWZZ J AD Switch,Push Type[Disc Detect 1]
SWB102 QSW-P9005AWZZ J AD Switch,Push Type[Disc Detect 2]
SWB103 QSW-P9005AWZZ J AD Switch,Push Type[Disc Detect 3]
SWB104 QSW-P9003AWZZ J AD Switch,Push Type [Mode 1]
SWB105 QSW-P9003AWZZ J AD Switch,Push Type [Mode 2]
SWB106 QSW-P9003AWZZ J AD Switch,Push Type [Mode 3]
SWB107 QSW-P9003AWZZ J AD Switch,Push Type [Mode 4]
SWB108 QSW-P9003AWZZ J AD Switch,Push Type [Mode 5]
SWB109 QSW-P9004AWZZ J AE Switch,Push Type [Tray 1]
SWB110 QSW-P9004AWZZ J AE Switch,Push Type [Tray 2]
UNA901 VHPGP1F32R/-1 J AP Terminal,Digital Input
MD MECHANISM PARTS
2 LCHSM0089AWZZ J AH Drive Chassis (A)
3 LCHSM0090AWZZ J AH Drive Chassis (B)
4 LHLDX3007AWM1 J AH Cartridge Holder Ass’y
5 MLEVF0051AWM1 J AK Slider Lever Ass’y
7 MLEVF0046AWFW J AE Arm,Holder
8 MLEVF0047AWFW J AC Plate,Switch
9 MLEVF0048AWFW J AC Arm,H/A Shift
10 MLEVP0095AWZZ J AC Lever,Cam Plate
12 MSPRD0132AWFJ J AB Spring,Loading
14 MSPRP0030AWFJ J AB Spring,Grip
15 MSPRP0031AWFJ J AC Spring,Shaft
16 MSPRT0031AWFJ J AC Spring,Loading Arm
17 MSPRT0032AWFJ J AB Spring,Shift Arm
18 NGERH0085AWZZ J AC Gear,Loading (A)
19 NGERH0086AWZZ J AB Gear,Middle (A)
20 NGERH0087AWZZ J AB Gear,Middle (B)
21 NGERH0088AWZZ J AC Gear,Middle (C)
22 NGERH0089AWZZ J AC Gear,Middle (D)
24 NGERR0004AWZZ J AC Rack,Grip
27 NSFTD0006AWM1 J AG Drive Shaft Ass’y
28 NSFTM0019AWFW J AC Shaft,Pickup Slide
30 PCOVS3029AWFW J AG Cover,Shield,Top
31 PCOVS3033AWFW J AF Cover,Shield,Side
32 PCOVS3031AWFW J AG Cover,Shield,Bottom
33 PCUSG0045AWZZ J AC Cushion,Shield Cover
34 RCILH0113AFZZ J AS Magnetic Head
1 35 RCTRH8198AFZZ J BM MD Pickup Unit Ass’y
