Sharp CD-SW200 Service Manual

CD-SW200
20
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[14] CABINET PARTS
201 CCABA6230AW01 BD Front Panel Ass'y
201- 1 -------- — Front Panel (Not Replacement Item)
201- 2 GCOVAA091AWSA AG Cover,Cassette [Tape 1]
201- 3 GCOVAA092AWSA AG Cover,Cassette [Tape 2]
201- 4 GDORF0127AWSA AE Holder,Cassette [Tape 1]
201- 5 GDORF0128AWSA AE Holder,Cassette [Tape 2]
201- 6 HDECQA167AWSA AE Panel,Cassette [Tape 1]
201- 7 HDECQA168AWSA AE Panel,Cassette [Tape 2]
201- 8 JKNBZA116AWSA AD Button,Disc Number
201- 9 MLIF-A001AWZZ AD Damper
201-10 JKNBZA128AWSA Button,Operation A
201-11 JKNBZA129AWSA Button,Operation B
201-12 JKNBZA113AWSA AG Button,Function
201-13 JKNBZA117AWSA AD Button,Memory
201-14 JKNBZA115AWSA AD Button,Tuning
201-15 JKNBZA114AWSA AD Button,Power
201-16 GCOVA1533AWSA AC Cover,Timer
201-17 HBDGB1007AWSA AD Badge,SHARP
201-18 MSPRDA002AWFJ AB Spring,Cassette [Tape 1]
201-19 MSPRDA003AWFJ AB Spring,Cassette [Tape 2]
201-20 HDECQA039AWSA AH Volume Knob Ring,A
201-21 HDECQA166AWSA AG Volume Knob Ring,B
201-22 HDECQA162AWSA AH Decoration Plate,Amp.
201-23 MLOKC0014AWZZ AC Lock,Cassette [Tape 1]
201-24 MLOKC0015AWZZ AC Lock,Cassette [Tape 2]
201-25 MSPRD0196AWFJ AB Spring,Cassette Lock [Tape 1]
201-26 MSPRD0197AWFJ AC Spring,Cassette Lock [Tape 2]
202 GCAB-A029AWSA AY Cabinet,Top/Side
203 PCUSGA048AWZZ Cushion,Leg
204 GITASA104AWSA AH Rear Panel,B
205 GCOVA1520AWSA AG Cover,CD Tray
206 LCHSZ0025AWZZ AM Chassis,Changer
207 PSLDMA009AWFW AG Shield,Dust Cover
208 92LNBAND1318A AA Nylon Band,80mm
209 KMECBA001AWZZ BC Tape Mechanism Ass'y
210 HDECQ1110AWSA AF Panel,Edge Light
212 QCNWN1860AWZZ AC Lug Wire
213 JKNBK0103AWSA AD Knob,Volume
214 HDECQ1104AWSA AL Cover,Volume Knob
216 92LCSPR1431C AA Spring,Ring
217 LCHSMA029AWFW AS Chassis,Main
218 GITARA265AWSA AP Rear Panel,A
219 LBND-1011AWZZ AA Nylon Band
!
220 QACCD0022AWZZ AM AC Power Supply Cord
221 LBSHC0005AWZZ AD Bushing,AC Power Supply Cord
222 NFANP0001AWZZ AD Rotary Fan
223 LANGK0437AWFW AE Bracket,Fan Support A
!
224 92LFSHOLD1652 AB Holder,Fuse
225 PRDARA072AWFW AZ Heat Sink
226 LHLDZ9024AWZZ AD Holder,Edge Light
227 LANGT0042AWFW AC Bracket,PWB Support
229 LHLDZA004AWZZ AC Holder,Rib Support
232 PFLT-A006AWZZ AB Felt
233 PSLDMA008AWFW AD Bracket,Tuner PWB
234 PRDARA079AWFW AL Heat Sink,Sub
235 LANGK0435AWFW AF Bracket Heat Sink Support
601 XJBSD30P10000 AA Screw,M3x10mm
602 XEBSD30P10000 AA Screw,M3x10mm
604 XEBSD26P10000 AA Screw,M2.6x10mm
605 XESSD30P10000 AA Screw,M3x10mm
606 XJSSD30P08000 AA Screw,M3x8mm
607 LX-EZ0010AWFD AA Screw,Special
608 XHBSD40P08000 AA Screw,M4x8mm
609 XBBSD20P04000 AA Screw,M2x4mm
610 LX-JZ0010AFFD AA Screw,M3x10mm
613 LX-JZ0037AWFD AB Screw,M3x18mm
614 LX-JZ0044AWFF AB Screw,M3x10mm
615 XWHSD32-10080 AA Washer,M3.2xM8x1mm
616 XHBSD30P06000 AA Screw,M3x6mm
617 LX-JZ0010AWFD AB Screw,M3x10mm
618 XJBSD30P08000 AA Screw,M3x8mm
619 LX-JZ0036AWFD AB Screw,Special
