CD-SW200
1 – 1
AudioCD-SW200Service ManualCD-SW200MarketE
CHAPTER 1. GENERAL DESCRIPTION
[1] Specifications
General
Amplifier
Power source AC 120 V, 60 Hz
Power consumption
195 W
Dimensions Width: 10-1/4" (260 mm)
Height: 13" (330 mm)
Depth: 12-7/8" (326 mm)
Weight 22.9 lbs. (10.4 kg)
Output power Front Speaker: 115 watts minimum RMS per
channel into 6 ohms from 100Hz to 20 kHz,
10% total harmonic distortion.
Subwoofer: 220 watts RMS into 12 ohms
from 50Hz to 120 Hz, 10% total harmonic
distortion.
Output terminals Front Speakers: 6 ohms
Subwoofer: 12 ohms
Headphones: 16 - 50 ohms
(recommended: 32 ohms)
Video output: 1Vp-p
Input terminals Game/ Auxiliary (audio signal):
500 mV/ 47 k ohms
Game/Video: 1Vp-p
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
Specifications for this model are subject to change without
prior notice.
CD-SW200
CP-S200
CP-SW200
CD player
Tuner
Cassette deck
Type 5-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser
pickup
D/A converter 1-bit D/A converter
Frequency
response
20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Frequency range FM: 87.5 - 108.0 MHz
AM: 530 - 1,720 kHz
Frequency
response
50 - 14,000 Hz (normal tape)
Signal/noise ratio 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter 0.3 % (WRMS)
Type 3-way type speaker system
Super tweeter
2" (5 cm) tweeter
5-1/8" (13 cm) woofer
Maximum input
power
230 W
Rated input power 115 W
Impedance 6 ohms
Dimensions Width: 7-1/16" (180 mm)
Height: 13" (330 mm)
Depth: 8-6/16" (212 mm)
Weight 6.6 lbs. (3.0 kg) /each
Type Full Range
8" (20 cm) subwoofer
Maximum input
power
440 W
Rated input power 220 W
Impedance 12 ohms
Dimensions Width: 9-13/16" (250 mm)
Height: 13" (330 mm)
Depth: 11-9/16" (294 mm)
Weight 13 lbs. (5.9 kg)
To Next Page
