CD-SW200
2 – 17
ITEM 2 , 3 MUST APPLY GREASE ON TOP SIDE GEAR ONLY
O.K
N.G
TOP VIEW AFTER
ASSY
FIX REVERSE N.G
GEAR 112 GEAR 112
134
133
132
13
