CD-SW200
2 – 21
APPLY GREASE
ASSY REVERSELY N.G
BIG SLOT MUST FACING OUT
WHEN FIX & AFTER FIX TO BASE CHASSIS
AFTER ASSY CONFIRM THE FREE DROP
GEAR POSITION DURING FIXING
103 137 136
17
