Sharp CX51N3 Service Manual

11
11-1 11-2
CX51N3/N4
MEMORY MAP
ADDRESS DATA
00 PASS WORD 55 00-FF
01
PASS WORD 4F 00-FF
02
PASS WORD 43 00-FF
03
PASS WORD A1 00-FF
04
05
06
AGC TAKE-OVER 0E 00-3F
07
V-SLOPE 20 00-3F
08
V-AMPLITUDE 20 00-3F
09
V-CENTER 20 00-3F
0A
H-CENTER 20 00-3F
0B
H-SIZE 20 00-3F
0C
EW-PARALLELOGRAM 20 00-3F
0D
EW-PARABOLA/WIDTH 20 00-3F
0E
EW-UPPER CORNER 20 00-3F
0F
EW-LOWER CORNER 20 00-3F
10
EW-TRAPEZIUM 20 00-3F
11
HORIZONTAL-BOW 20 00-3F
12
S-CORRECTION 00 00-3F
13
14
15
16
DRIVE-R (STANDARD) 20 00-3F
17
DRIVE-G (STANDARD) 20 00-3F
18
DRIVE-B (STANDARD) 20 00-3F
19
DRIVE-R (WARM) 20 00-3F
1A
DRIVE-G (WARM) 20 00-3F
1B
DRIVE-B (WARM) 20 00-3F
1C
DRIVE-R (COOL) 19 00-3F
1D
DRIVE-G (COOL) 20 00-3F
1E
DRIVE-B (COOL) 20 00-3F
1F
20
21
22
SUB-VOLUME 3F 00-3F
23
SUB-CONTRAST 3F 00-3F
24
SUB-COLOUR 20 00-3F
25
SUB-BRIGHTNESS 20 00-3F
26
SUB-TINT 20 00-3F
27
SUB-SHARPNESS 20 00-3F
28
HTL-VOLUME 20 00-3F
29
HTL-POSITION FF 00-FF
2A
2B
2C
2D
OSD-REFERENCE 0F 00-0F
2E
CUTOFF LEVEL -OFFSET R 20 00-3F
2F
CUTOFF LEVEL -OFFSET G 20 00-3F
30
CATHODE DRIVE LEVEL 00 00-0F
31
Y-DELAY (TV PAL) 0C 00-0F
32
Y-DELAY (TV SECAM) 0F 00-0F
33
Y-DELAY (TV N358) 0C 00-0F
34
Y-DELAY (TV N443) 0C 00-0F
35
Y-DELAY (TV BW) 0C 00-0F
36
Y-DELAY (AV PAL) 0C 00-0F
37
Y-DELAY (AV SECAM) 0F 00-0F
38
Y-DELAY (AV N358) 0C 00-0F
39
Y-DELAY (AV N443) 0C 00-0F
3A
Y-DELAY (AV BW) 0C 00-0F
3B
COLOUR-OFFSET (PAL) 08 00-0F
3C
COLOUR-OFFSET (SECAM) 08 00-0F
3D
COLOUR-OFFSET (N358) 04 00-0F
3E
COLOUR-OFFSET (N443) 04 00-0F
3F
SHARPNESS-OFFSET (PAL) 08 00-0F
MODEL MODEL
LETTER NO. LETTER NO.
(1) 20th August
2001:Change of
range & default.
MICON EEPROM EEPROM CHASSIS CTV FINAL
LAST INITIAL
SETTING DATA
(HEX) D7 D6 D5 D4 D3 D2 D1 D0 DEFAULT RANGE WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE
REMARK
HEADPHONE JACK CHECKING
NO. Adjustment part Adjusting procedure and conditions Waveform and others
1 HEADPHONE
OUTPUT
CHECKING
1. Receive PAL COLOUR PAR with SOUND
400Hz, 100% MODULATION (±50kHz Dev).
2. Maximum volume, and check the headphone
output with 400Hz sound and no sound out
from speaker.
