12-1 12-2
CX51N3/N4
12
ADDRESS DATA
(HEX) D7 D6 D5 D4 D3 D2 D1 D0
80 TUNING FREQUANCY (HIGHER PART) POS 4
81 TUNING FREQUANCY (LOWER PART)
82 S-SYS AFT (auto) C-SYS
83 TUNING FREQUANCY (HIGHER PART) POS 5
84 TUNING FREQUANCY (LOWER PART)
85 S-SYS AFT (auto) C-SYS
86 TUNING FREQUANCY (HIGHER PART) POS 6
87 TUNING FREQUANCY (LOWER PART)
88 S-SYS AFT (auto) C-SYS
89 TUNING FREQUANCY (HIGHER PART) POS 7
8A TUNING FREQUANCY (LOWER PART)
8B S-SYS AFT (auto) C-SYS
8C TUNING FREQUANCY (HIGHER PART) POS 8
8D TUNING FREQUANCY (LOWER PART)
8E S-SYS AFT (auto) C-SYS
8F TUNING FREQUANCY (HIGHER PART) POS 9
90 TUNING FREQUANCY (LOWER PART)
91 S-SYS AFT (auto) C-SYS
92 TUNING FREQUANCY (HIGHER PART) POS 10
93 TUNING FREQUANCY (LOWER PART)
94 S-SYS AFT (auto) C-SYS
95 TUNING FREQUANCY (HIGHER PART) POS 11
96 TUNING FREQUANCY (LOWER PART)
97 S-SYS AFT (auto) C-SYS
98 TUNING FREQUANCY (HIGHER PART) POS 12
99 TUNING FREQUANCY (LOWER PART)
9A S-SYS AFT (auto) C-SYS
9B TUNING FREQUANCY (HIGHER PART) POS 13
9C TUNING FREQUANCY (LOWER PART)
9D S-SYS AFT (auto) C-SYS
9E TUNING FREQUANCY (HIGHER PART) POS 14
9F TUNING FREQUANCY (LOWER PART)
A0 S-SYS AFT (auto) C-SYS
A1 TUNING FREQUANCY (HIGHER PART) POS 15
A2 TUNING FREQUANCY (LOWER PART)
A3 S-SYS AFT (auto) C-SYS
A4 TUNING FREQUANCY (HIGHER PART) POS 16
A5 TUNING FREQUANCY (LOWER PART)
A6 S-SYS AFT (auto) C-SYS
A7 TUNING FREQUANCY (HIGHER PART) POS 17
A8 TUNING FREQUANCY (LOWER PART)
A9 S-SYS AFT (auto) C-SYS
AA TUNING FREQUANCY (HIGHER PART) POS 18
AB TUNING FREQUANCY (LOWER PART)
AC S-SYS AFT (auto) C-SYS
AD TUNING FREQUANCY (HIGHER PART) POS 19
AE TUNING FREQUANCY (LOWER PART)
AF S-SYS AFT (auto) C-SYS
B0 TUNING FREQUANCY (HIGHER PART) POS 20
B1 TUNING FREQUANCY (LOWER PART)
B2 S-SYS AFT (auto) C-SYS
B3 TUNING FREQUANCY (HIGHER PART) POS 21
B4 TUNING FREQUANCY (LOWER PART)
B5 S-SYS AFT (auto) C-SYS
B6 TUNING FREQUANCY (HIGHER PART) POS 22
B7 TUNING FREQUANCY (LOWER PART)
B8 S-SYS AFT (auto) C-SYS
B9 TUNING FREQUANCY (HIGHER PART) POS 23
BA TUNING FREQUANCY (LOWER PART)
BB S-SYS AFT (auto) C-SYS
BC TUNING FREQUANCY (HIGHER PART) POS 24
BD TUNING FREQUANCY (LOWER PART)
BE S-SYS AFT (auto) C-SYS
BF TUNING FREQUANCY (HIGHER PART) POS 25
MODEL MODEL
LETTER NO. LETTER NO.
MICON EEPROM EEPROM CHASSIS CTV FINAL
LAST INITIAL
SETTING DATA
DEFAULT RANGE WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE
REMARK
ADDRESS DATA
(HEX) D7 D6 D5 D4 D3 D2 D1 D0
40 SHARPNESS-OFFSET (SECAM) 04 00-0F
41
SHARPNESS-OFFSET (N358) 0C 00-0F
42
SHARPNESS-OFFSET (N443) 08 00-0F
43
44
FCO ACL OSO EHT EVG FFI AVL BKS 00-FF
45
SECAM N443 N358 PB-SECAM BG I DK M 00-FF
46
SM1 SM0 FMWS AV BTSC HTL VMC VMI 00-FF
47
HP2 FSL RUS FRA CHN MLY ARB THA 00-FF
48
AGC1 AGC0 BIL CPTFOB-AV FOA-AV FOB-FE FOA-FE
NDF MSA LED-F
00-FF
00-F3
49
4A
4B
4C
VOLUME 01 00-3C
4D
CONTRAST 3C 00-3C
4E
COLOUR 1E 00-3C
4F
BRIGHTNESS 1E 00-3C
50
TINT 1E 00-3C
51
SHARPNESS 1E 00-3C
52
53
54
55
POSITION/AV1/AV2 01 00-FF
56
FAV-POS A 0A 00-FF
57
FAV-POS B 14 00-FF
58
FAV-POS C 1E 00-FF
59
FAV-POS D 28 00-FF
5A
5B
5C
LAST POWER MODE 00 00-01
5D
WHITE-TEMP 00 00-02
5E
BLUE BACK 00 00-01
5F
LANGUAGE 00 00-07
60
LAST DIGIT MODE (1 OR 2) 00 00-01
61
62
SKIP 0 SKIP 1 SKIP 2 SKIP 3 SKIP 4 SKIP 5 SKIP 6 SKIP 7 80 00-FF
63
SKIP 8 SKIP 9 SKIP 10 SKIP 11 SKIP 12 SKIP 13 SKIP 14 SKIP 15 00 00-FF
64
SKIP 16 SKIP 17 SKIP 18 SKIP 19 SKIP 20 SKIP 21 SKIP 22 SKIP 23 00 00-FF
65
SKIP 24 SKIP 25 SKIP 26 SKIP 27 SKIP 28 SKIP 29 SKIP 30 SKIP 31 00 00-FF
66
SKIP 32 SKIP 33 SKIP 34 SKIP 35 SKIP 36 SKIP 37 SKIP 38 SKIP 39 00 00-FF
67
SKIP 40 SKIP 41 SKIP 42 SKIP 43 SKIP 44 SKIP 45 SKIP 46 SKIP 47 00 00-FF
68
SKIP 48 SKIP 49 SKIP 50 SKIP 51 SKIP 52 SKIP 53 SKIP 54 SKIP 55 00 00-FF
69
SKIP 56 SKIP 57 SKIP 58 SKIP 59 SKIP 60 SKIP 61 SKIP 62 SKIP 63
00 00-FF
6A
SKIP 64 SKIP 65 SKIP 66 SKIP 67 SKIP 68 SKIP 69 SKIP 70 SKIP 71
00 00-FF
6B
SKIP 72 SKIP 73 SKIP 74 SKIP 75 SKIP 76 SKIP 77 SKIP 78 SKIP 79 00 00-FF
6C
SKIP 80 SKIP 81 SKIP 82 SKIP 83 SKIP 84 SKIP 85 SKIP 86 SKIP 87 00 00-FF
6D
SKIP 88 SKIP 89 SKIP 90 SKIP 91 SKIP 92 SKIP 93 SKIP 94 SKIP 95 00 00-FF
6E
SKIP 96 SKIP 97 SKIP 98 SKIP 99 00 00-FF
6F
70
71
72
73
74
TUNING FREQUANCY (HIGHER PART) S-SYS POS 0
75 TUNING FREQUANCY (LOWER PART) 000:BG
76
S-SYS AFT (auto) C-SYS 001:I
77
TUNING FREQUANCY (HIGHER PART) 010:DK POS 1
78 TUNING FREQUANCY (LOWER PART) 011:M
79
S-SYS AFT (auto) C-SYS
7A TUNING FREQUANCY (HIGHER PART) AFT POS 2
7B TUNING FREQUANCY (LOWER PART) 0:OFF
7C
S-SYS AFT (auto) C-SYS 1:ON
7D
TUNING FREQUANCY (HIGHER PART) POS 3
7E TUNING FREQUANCY (LOWER PART)
7F S-SYS AFT (auto) C-SYS
MODEL MODEL
LETTER NO. LETTER NO.
1B
DE
53
3E
C4
00
MICON EEPROM EEPROM CHASSIS CTV FINAL
LAST INITIAL
SETTING DATA
DEFAULT RANGE WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE
REMARK
(1) 20th August 2001:
Added 3 new items.
