CX51N3/N4
ADDRESS DATA
(HEX) D7 D6 D5 D4 D3 D2 D1 D0
100 POS 46
101 TUNING FREQUANCY (HIGHER PART) POS 47
102 TUNING FREQUANCY (LOWER PART)
103 S-SYS AFT (auto) C-SYS
S-SYS AFT (auto) C-SYS
104 TUNING FREQUANCY (HIGHER PART) POS 48
105 TUNING FREQUANCY (LOWER PART)
106 S-SYS AFT (auto) C-SYS
107 TUNING FREQUANCY (HIGHER PART) POS 49
108 TUNING FREQUANCY (LOWER PART)
109 S-SYS AFT (auto) C-SYS
10A TUNING FREQUANCY (HIGHER PART) POS 50
10B TUNING FREQUANCY (LOWER PART)
10C S-SYS AFT (auto) C-SYS
10D TUNING FREQUANCY (HIGHER PART) POS 51
10E TUNING FREQUANCY (LOWER PART)
10F S-SYS AFT (auto) C-SYS
110 TUNING FREQUANCY (HIGHER PART) POS 52
111 TUNING FREQUANCY (LOWER PART)
112 S-SYS AFT (auto) C-SYS
113 TUNING FREQUANCY (HIGHER PART) POS 53
114 TUNING FREQUANCY (LOWER PART)
115 S-SYS AFT (auto) C-SYS
116 TUNING FREQUANCY (HIGHER PART) POS 54
117 TUNING FREQUANCY (LOWER PART)
118 S-SYS AFT (auto) C-SYS
119 TUNING FREQUANCY (HIGHER PART) POS 55
11A TUNING FREQUANCY (LOWER PART)
11B S-SYS AFT (auto) C-SYS
11C TUNING FREQUANCY (HIGHER PART) POS 56
11D TUNING FREQUANCY (LOWER PART)
11E S-SYS AFT (auto) C-SYS
11F TUNING FREQUANCY (HIGHER PART) POS 57
120 TUNING FREQUANCY (LOWER PART)
121 S-SYS AFT (auto) C-SYS
122 TUNING FREQUANCY (HIGHER PART) POS 58
123 TUNING FREQUANCY (LOWER PART)
124 S-SYS AFT (auto) C-SYS
125 TUNING FREQUANCY (HIGHER PART) POS 59
126 TUNING FREQUANCY (LOWER PART)
127 S-SYS AFT (auto) C-SYS
128 TUNING FREQUANCY (HIGHER PART) POS 60
129 TUNING FREQUANCY (LOWER PART)
12A S-SYS AFT (auto) C-SYS
12B TUNING FREQUANCY (HIGHER PART) POS 61
12C TUNING FREQUANCY (LOWER PART)
12D S-SYS AFT (auto) C-SYS
12E TUNING FREQUANCY (HIGHER PART) POS 62
12F TUNING FREQUANCY (LOWER PART)
130 S-SYS AFT (auto) C-SYS
131 TUNING FREQUANCY (HIGHER PART) POS 63
132 TUNING FREQUANCY (LOWER PART)
133 S-SYS AFT (auto) C-SYS
134 TUNING FREQUANCY (HIGHER PART) POS 64
135 TUNING FREQUANCY (LOWER PART)
136 S-SYS AFT (auto) C-SYS
137 TUNING FREQUANCY (HIGHER PART) POS 65
138 TUNING FREQUANCY (LOWER PART)
139 S-SYS AFT (auto) C-SYS
13A TUNING FREQUANCY (HIGHER PART) POS 66
13B TUNING FREQUANCY (LOWER PART)
13C S-SYS AFT (auto) C-SYS
13D TUNING FREQUANCY (HIGHER PART) POS 67
13E TUNING FREQUANCY (LOWER PART)
13F S-SYS AFT (auto) C-SYS
MODEL MODEL
LETTER NO. LETTER NO.
MICON EEPROM EEPROM CHASSIS CTV FINAL
LAST INITIAL
SETTING DATA
DEFAULT RANGE WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE
REMARK
ADDRESS DATA
(HEX) D7 D6 D5 D4 D3 D2 D1 D0
C0 TUNING FREQUANCY (LOWER PART) POS 25
C1 S-SYS AFT (auto) C-SYS
C2 TUNING FREQUANCY (HIGHER PART) POS 26
C3 TUNING FREQUANCY (LOWER PART)
C4 S-SYS AFT (auto) C-SYS
C5 TUNING FREQUANCY (HIGHER PART) POS 27
C6 TUNING FREQUANCY (LOWER PART)
C7 S-SYS AFT (auto) C-SYS
C8 TUNING FREQUANCY (HIGHER PART) POS 28
C9 TUNING FREQUANCY (LOWER PART)
CA S-SYS AFT (auto) C-SYS
CB TUNING FREQUANCY (HIGHER PART) POS 29
CC TUNING FREQUANCY (LOWER PART)
CD S-SYS AFT (auto) C-SYS
CE TUNING FREQUANCY (HIGHER PART) POS 30
CF TUNING FREQUANCY (LOWER PART)
D0 S-SYS AFT (auto) C-SYS
D1 TUNING FREQUANCY (HIGHER PART) POS 31
D2 TUNING FREQUANCY (LOWER PART)
D3 S-SYS AFT (auto) C-SYS
D4 TUNING FREQUANCY (HIGHER PART) POS 32
D5 TUNING FREQUANCY (LOWER PART)
D6 S-SYS AFT (auto) C-SYS
D7 TUNING FREQUANCY (HIGHER PART) POS 33
D8 TUNING FREQUANCY (LOWER PART)
D9 S-SYS AFT (auto) C-SYS
DA TUNING FREQUANCY (HIGHER PART) POS 34
DB TUNING FREQUANCY (LOWER PART)
DC S-SYS AFT (auto) C-SYS
DD TUNING FREQUANCY (HIGHER PART) POS 35
DE TUNING FREQUANCY (LOWER PART)
DF S-SYS AFT (auto) C-SYS
E0 TUNING FREQUANCY (HIGHER PART) POS 36
E1 TUNING FREQUANCY (LOWER PART)
E2 S-SYS AFT (auto) C-SYS
E3 TUNING FREQUANCY (HIGHER PART) POS 37
E4 TUNING FREQUANCY (LOWER PART)
E5 S-SYS AFT (auto) C-SYS
E6 TUNING FREQUANCY (HIGHER PART) POS 38
E7 TUNING FREQUANCY (LOWER PART)
E8 S-SYS AFT (auto) C-SYS
E9 TUNING FREQUANCY (HIGHER PART) POS 39
EA TUNING FREQUANCY (LOWER PART)
EB S-SYS AFT (auto) C-SYS
EC TUNING FREQUANCY (HIGHER PART) POS 40
ED TUNING FREQUANCY (LOWER PART)
EE S-SYS AFT (auto) C-SYS
EF TUNING FREQUANCY (HIGHER PART) POS 41
F0 TUNING FREQUANCY (LOWER PART)
F1 S-SYS AFT (auto) C-SYS
F2 TUNING FREQUANCY (HIGHER PART) POS 42
F3 TUNING FREQUANCY (LOWER PART)
F4 S-SYS AFT (auto) C-SYS
F5 TUNING FREQUANCY (HIGHER PART) POS 43
F6 TUNING FREQUANCY (LOWER PART)
F7 S-SYS AFT (auto) C-SYS
F8 TUNING FREQUANCY (HIGHER PART) POS 44
F9 TUNING FREQUANCY (LOWER PART)
FA S-SYS AFT (auto) C-SYS
FB TUNING FREQUANCY (HIGHER PART) POS 45
FC TUNING FREQUANCY (LOWER PART)
TUNING FREQUANCY (HIGHER PART)
TUNING FREQUANCY (LOWER PART)
FD S-SYS AFT (auto) C-SYS
FE POS 46
FF
MODEL MODEL
LETTER NO. LETTER NO.
MICON EEPROM EEPROM CHASSIS CTV FINAL
LAST INITIAL
SETTING DATA
DEFAULT RANGE WRITE(CPU) CHECK DATA CHECK TYPE CHECK DATA CHECK TYPE
REMARK
