FO-4450U/FO-CS1
16
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[13] 2nd paper cassette(2)(FO-CS1)
1 GCABG2412XHSA BM D Cassette cabinet
2 LPLTP3023XHZZ AF C Lever joint 1
3 LPLTP3044XHZZ AF C Lever joint 2
4 MLEVP2309XHZZ AE C Release lever
5 MSPRC3095XHZZ AD C Pinch roller spring
6 MSPRD3093XHZZ AG C Release lever spring
7 NROLP2334XHZA AC C Pinch roller
8 NSFTZ2309XHZZ AC C Pinch roller shaft
9 NSFTZ2312XHZZ AC C Release shaft
10 CMOTZ2180XH02 BD E Drive system unit
11 CROLR2595XH01 AQ C PU roller unit
12 DCEKZ426CXH01 BK E 2nd option cassette PWB unit
15 LBSHP2109XHZZ AF C Drive bearing
16 LBSHP2113XHZA AE C Drive roller bearing
17 LHLDZ2239XHZZ AE C Lock nail holder
18 LPINS2032XHZZ AF C Roller pin
19 LPLTM3238XHZZ BD C Bottom plate
20 LPLTM3239XHZZ AR C Front support bracket
21 LPLTP3242XHZZ AE C Sensor guide plate
22 LPLTP3252XHZZ AE C Lock release plate
23 LRALP2025XHZZ AL C Cassette nail,right
24 LRALP2026XHZZ AL C Cassette nail,left
25 MLEVP2308XHZZ AD C Paper sensor lever
26 MLOK-2008XHZZ AC C Cassette lock piece
27 MSPRC3181XHZZ AD C Clutch spring
28 MSPRC3378XHZZ AE C Cassette lock spring
29 NGERH2469XHZZ AC C Paper feed clutch gear
30 NGERH2472XHZZ AA C Idler gear(30Z)
32 NROLP2493XHZZ AE C Slide roller
33 NROLR2496XHZZ AU C Drive roller
34 NSFTZ2365XHZZ AS C Cassette up roller shaft
35 PGIDM2643XHZZ AL C Cassette paper guide
36 GLEGG2082XHZZ AE C Foot
37 QCNW-4964XHZZ AF C Paper size cable
38 QCNWN272BXHZZ AH C Cassette size sensor cable
39 QSW-M2323XHZZ AQ C Paper size sensor
40 QSW-M2219SCZZ AD C Cassette size sensor
41 MSPRD3404XHZZ AH C Earth spring
42 LBSHP2147XHZZ AE C PU roller bearing
!
43 RCORF2146XHZZ AG B Core
44 QCNWN264BXHZZ AU C 2nd cassette cable(15pin)
45 LBNDJ2006XHZZ AA C Band(100mm)
46 TLABZ462FXHZZ AE C Skid sheet
B1 LX-BZ2205XHZZ AC C Screw(3x8)
B2 LX-BZ2291XHZZ AE C Cassette special screw
B3 XEBSD30P10000 AA C Screw(3x10)
B4 XHBSD30P06000 AA C Screw(3x6)
B5 XHBSD30P10000 AA C Screw(3x10)
B6 XHBSE30P12000 AA C Screw(3x12)
